Salus iT500 User Manual

iT500 User Reference Manual
64
For example:
4. When the required override is selected, press
. The Home screen will then be displayed again, with the
relevant indicator displayed to show that central heating for the zone has been turned o.
To turn programmed hot water on, follow the above procedure, and reset the unit to AUTO from ON, 1 or OFF
using the
or . buttons and press .
Other Overrides
Two additional types of override can be set:
• Energy Save override, which will use the lowest set temperature on your daily schedule.
• Holiday override, which for a set period of time changes the central heating setpoint to the same as the
Frost Protection setpoint (see below).
If Frost Protection is switched on, this may also result in the normal programming being overridden, as
explained below.
If the Energy Save override is on, the
is displayed on the iT500 screen.
If the Holiday override is on, the
icon is displayed.
Both these overrides can only be set using the Smartphone App or via the PC, however they may be turned
o locally if required.
To cancel either of these overrides, press
to de-activate the override. The relevant icon ashes.
Press
to conrm switching o the override.

Salus iT500 Specifications

General

Frequency	868 MHz
Interface	Z-Wave
Control type	Touch
Product color	Black, Silver
Smart thermostat	Yes
Units of measurement	°C
Maximum outdoor range	30 m
Temperature range (T-T)	5 - 35 °C
Battery type	AA
Operating voltage	2 V
Number of batteries supported	2
Handheld remote control	No

Weight and Dimensions

Depth	30 mm
Width	128 mm
Height	95 mm
