Samsung AQ09UGFN User Manual

11
ENGLISH
Press the button to turn on the air conditioner.
Press the
button to set the operating mode.
• EachtimeyoupresstheMode button, the mode will change in order of Auto, Cool, Dry, Fan and Heat.
Press the button to set the desired fan speed.
Auto (Auto)
Cool
(Auto), (Low), (Med), (High)
Dry
(Auto)
Fan (Low), (Med), (High)
Heat
(Auto), (Low), (Med), (High)
Press the button to adjust the temperature.
Auto You can adjust the desired temperature by 1°C within the range of 16°C~30°C.
Cool You can adjust the desired temperature by 1°C within the range of 16°C~30°C.
Dry You can adjust the desired temperature by 1°C within the range of 18°C~30°C.
Fan Temperature adjustment is not possible.
Heat You can adjust the desired temperature by 1°C within the range of 16°C~30°C.
• Airowcanbeadjustedmanually.(seepage12forinstructions.)
Boracay EUR_AQ09T&U@_IBIM_32447A_E.indd 11 2011-3-19 10:07:39

Samsung AQ09UGFN Specifications

General

Indoor unit type	Wall-mountable
Indoor unit weight	7800 g
Indoor units quantity	1
Indoor unit dimensions (WxDxH)	820 x 190 x 285 mm
Type	Split system
Remotely operated	Yes
Refrigerating medium	R410A
Cooling capacity (max)	9384 BTU/h
Dehumidifying capacity	1 l/h
Heating capacity (max)	9896 BTU/h
Air conditioner functions	cooling, dehumidifying, heating
Cooling capacity in watts (max)	2750 W
Heating capacity in watts (max)	2900 W
Cooling energy efficiency (EER, W/W)	3.22
Heating energy efficiency (COP, W/W)	3.61
Airflow	7.5 m³/h
Outdoor units quantity	0
Noise level (low speed)	24 dB
Noise level (high speed)	32 dB
Power requirements	AC 220 - 240 V, 50 Hz
Annual energy consumption	428 kWh
Power consumption (cooling) (max)	855 W
Power consumption (heating) (max)	803 W
