Adjusting the air  ow direction
Air  ow can be directed to your desired position.
Turbo function will be helpful to cool your room quickly and e ectively.
Vertical air  ow
Horizontal air  ow
Air  ow blades move up and down.
Make sure one of the blade pin lever that stick out of the air  ow blades are not broken.
Press the Air swing
button on the remote controller.

Air swing indicator will be on and air  ow blades move up and down continuously to
circulate the air.
 
Press the Air swing button on the remote controller again, to keep the air  ow
direction in a constant position.
Press the Turbo button on the remote controller during Cool mode.

Turbo indicator appears on the remote controller display and the air conditioner
operates in Turbo function for 30 minutes.
Move the blade pin lever left or right to keep the air  ow direction in a constant
position you prefer.
Press the
 
Press the
• BeextremelycarefulwithyourngerswhileadjustingtheHorizontal
air  ow direction.
There is a potential risk of personal injury when the unit is
mishandled.
Using the Turbo function
Blade pin lever
• TurbofunctionisonlyavailableinCoolmode.
• IfyoupresstheMode button while the Turbo function is on, it will cancel
the function.
• Temperature/Fanspeedcannotbeadjustedwhileusingthisfunction.
Press the Turbo button once again.Cancel
Boracay EUR_AQ09T&U@_IBIM_32447A_E.indd 12 2011-3-19 10:07:42

Samsung AQ09UGFN Specifications

General

Indoor unit type	Wall-mountable
Indoor unit weight	7800 g
Indoor units quantity	1
Indoor unit dimensions (WxDxH)	820 x 190 x 285 mm
Type	Split system
Remotely operated	Yes
Refrigerating medium	R410A
Cooling capacity (max)	9384 BTU/h
Dehumidifying capacity	1 l/h
Heating capacity (max)	9896 BTU/h
Air conditioner functions	cooling, dehumidifying, heating
Cooling capacity in watts (max)	2750 W
Heating capacity in watts (max)	2900 W
Cooling energy efficiency (EER, W/W)	3.22
Heating energy efficiency (COP, W/W)	3.61
Airflow	7.5 m³/h
Outdoor units quantity	0
Noise level (low speed)	24 dB
Noise level (high speed)	32 dB
Power requirements	AC 220 - 240 V, 50 Hz
Annual energy consumption	428 kWh
Power consumption (cooling) (max)	855 W
Power consumption (heating) (max)	803 W
