Samsung ML-1520 User Manual

S ETTING U P Y OUR P RINTER
2.8
Changing the Paper Size in the Tray
1 Pinch the rear guide as shown below to adjust for the paper
length.
2 Pinch the side guide as shown and slide it to the left flush
against the paper.
Notes:
• Do not push the width guide far enough to cause the material to
warp.
• If you do not adjust the width guide, it may cause paper jam.

Samsung ML-1520 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	11 s
Print speed (black, normal quality, A4/US Letter)	14 ppm
Internal memory	8 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	50 sheets

Weight and Dimensions

Dimensions (WxDxH)	348 x 355 x 193 mm
