Samsung ML-1520 User Manual

P RINTING T ASKS
4.29
4
Windows 2000/XP
Setting Up Host Computer
1 Start Windows.
2 From the Start menu, select Settings and Printers.
(Windows 2000)
From the Start menu, select Printers and Faxes.
(Windows XP)
3 Double-click your printer icon.
4 From the Printer menu, select Sharing.
5 Check the Shared As box. (Windows 2000)
Check the Share this printer box. (Windows XP)
Fill in the Shared Name field, and then click OK.
Setting Up Client PC
1 Right-click Start, and select Explorer.
2 Open your network folder in the left column.
3 Click the shared name.
4 From the Start menu, select Settings and Printers.
(Windows 2000)
From the Start menu, select Printers and Faxes.
(Windows XP)
5 Double-click your printer icon.
6 From the Printer menu, select Properties.
7 Press the Ports tab, and click Add Port.
8 Select Local Port, and click New Port.

Samsung ML-1520 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	11 s
Print speed (black, normal quality, A4/US Letter)	14 ppm
Internal memory	8 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	50 sheets

Weight and Dimensions

Dimensions (WxDxH)	348 x 355 x 193 mm
