Samsung OH55F User Manual

104
Configure options for external input devices connected to the product.
Keyboard Language
Configure the key combination used to change the input language.
Keyboard type
Specify the keyboard type.
Input Language Shortcut
Select shortcut keys for switching between input languages.
Input Device Manager
MENU mSystemInput Device ManagerENTER E
Input Device Manager
Keyboard Language
Keyboard type
Input Language Shortcut

The displayed image may differ depending on the model.
Select the appropriate Play via mode depending on the environment where you are using the product.
The home screen may be different depending on the setting.
 MagicInfo / URL Launcher
Play via
MENU mSystemPlay viaENTER E
System
Play via
MagicInfo

The displayed image may differ depending on the model.

Samsung OH55F Specifications

General

Panel life	- h
Color gamut	72 %
Pixel pitch	- mm
Touchscreen	-
Response time	6 ms
Display diagonal	55 \
Display brightness	2500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	96 - 123 Hz
Horizontal scan range	108 - 139.5 kHz
Contrast ratio (dynamic)	100000:1
Display number of colors	16.78 million colors
Supported graphics resolutions	1920 x 1080 (HD 1080)
DVI port	No
Ethernet LAN	Yes
DisplayPorts quantity	0
VGA (D-Sub) input ports	1
Operating hours (hours/days)	24/7
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Placement supported	Outdoor
Panel mounting interface	1186 x 560 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	292 W
Annual energy consumption	405 kWh
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Package depth	230 mm
Package width	1358 mm
Package height	845 mm
Package weight	58100 g
Cables included	AC

Weight and Dimensions

Depth	85 mm
Width	1260.6 mm
Height	731.4 mm
Weight	52600 g
