Video Wall
HOME Video WallENTER E
Video Wall

The displayed image may differ depending on the model.
Customise the layout of multiple displays that are connected to form a video wall.
In addition, display part of a whole picture or repeat the same picture on each of the connected multiple
displays.
To display multiple images, refer to MDC Help or the MagicInfo user guide. Some models may not support
the MagicInfo function.
Video Wall
You can activate or deactivate Video Wall.
To organise a video wall, select On.
 Off / On
Horizontal x Vertical
This feature automatically splits a videowall display based on a videowall matrix configuration.
Enter the videowall matrix.
The videowall display is split based on the configured matrix. The number of vertical or horizontal display
devices can be set within the range 1 and 15.

A videowall display can be split into a maximum of 100 screens.

The Horizontal x Vertical option is only enabled when Video Wall is set to On.
Screen Position
To rearrange split screens, adjust the number for each product in the matrix using the Screen Position
feature.
Selecting Screen Position will display the videowall matrix with the numbers assigned to the products
that form the videowall.
To rearrange products, use the direction buttons on the remote control to move a product to another
desired number. Press the E button.

Screen Position allows you to split the screen into a maximum of 100 views (15x15).

The Screen Position option is only enabled when Video Wall is set to On.

To use the function, make sure Horizontal x Vertical is configured.

Samsung OH55F Specifications

General

Panel life	- h
Color gamut	72 %
Pixel pitch	- mm
Touchscreen	-
Response time	6 ms
Display diagonal	55 \
Display brightness	2500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	96 - 123 Hz
Horizontal scan range	108 - 139.5 kHz
Contrast ratio (dynamic)	100000:1
Display number of colors	16.78 million colors
Supported graphics resolutions	1920 x 1080 (HD 1080)
DVI port	No
Ethernet LAN	Yes
DisplayPorts quantity	0
VGA (D-Sub) input ports	1
Operating hours (hours/days)	24/7
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Placement supported	Outdoor
Panel mounting interface	1186 x 560 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	292 W
Annual energy consumption	405 kWh
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Package depth	230 mm
Package width	1358 mm
Package height	845 mm
Package weight	58100 g
Cables included	AC

Weight and Dimensions

Depth	85 mm
Width	1260.6 mm
Height	731.4 mm
Weight	52600 g
