Control Codes
Viewing control state (Get control command)
Header Command ID Data length Checksum
0xAA Command type 0
Controlling (Set control command)
Header Command ID Data length Data Checksum
0xAA Command type 1 Value
Command
No. Command type Command Value range
1 Power control 0x11 0~1
2 Volume control 0x12 0~100
3 Input source control 0x14 -
4 Screen mode control 0x18 -
5 Screen size control 0x19 0~255
6 Video wall mode control 0x5C 0~1
7 Safety Lock 0x5D 0~1
8 Video Wall On 0x84 0~1
9 Video Wall User Control 0x89 -
 All communications take place in hexadecimals. The checksum is calculated by adding up all values
except the header. If a checksum adds up to be more than 2 digits as shown below (11+FF+01+01=112),
the first digit is removed.
E.g. Power On & ID=0
Header Command ID Data length Data 1 Checksum
0xAA 0x11 1 "Power"
Header Command ID Data length Data 1 12
0xAA 0x11 1 1
 To control all devices connected by a serial cable simultaneously irrespective of IDs, set the ID
as "0xFE" and transmit commands. Commands will be executed by each device but ACK will not
respond.

Samsung OH55F Specifications

General

Panel life	- h
Color gamut	72 %
Pixel pitch	- mm
Touchscreen	-
Response time	6 ms
Display diagonal	55 \
Display brightness	2500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	96 - 123 Hz
Horizontal scan range	108 - 139.5 kHz
Contrast ratio (dynamic)	100000:1
Display number of colors	16.78 million colors
Supported graphics resolutions	1920 x 1080 (HD 1080)
DVI port	No
Ethernet LAN	Yes
DisplayPorts quantity	0
VGA (D-Sub) input ports	1
Operating hours (hours/days)	24/7
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Placement supported	Outdoor
Panel mounting interface	1186 x 560 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	292 W
Annual energy consumption	405 kWh
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Package depth	230 mm
Package width	1358 mm
Package height	845 mm
Package weight	58100 g
Cables included	AC

Weight and Dimensions

Depth	85 mm
Width	1260.6 mm
Height	731.4 mm
Weight	52600 g
