Alarm input
You can set the alarm input type, activation time, and operation mode.
1. From the Setup menu, select the
<Event (
)> tab.
2. Click <Alarm input>.
3. Set whether or not to <Enable>.
4. Select the type.
• Normal open : It is normally open,
but if it is closed, an alarm will be
triggered.
• Normal close : It is normally closed,
but if it is open, an alarm will be
triggered.
5. Specify the <Activation time>.
• Always : Always check if an alarm occurs. It activates in operated mode when the
alarm occurs.
`
If set to <Always>, the activation time cannot be changed.
• Only scheduled time : Check if an alarm occurs at a specified day of the week for
a specified time period. It activates in operated mode when the alarm occurs.
• [Clear (
)] : Reset all settings.
• Minute : Click an area in Activation
Time and set the time by minutes.
• Hour : Drag your mouse at Activation
Time and set the time by hours.
J
`
The transfer interval setting value must be
smaller than the preset activation interval
to succeed in image transmission.
setup screen
122_ setup screen
