58_ network connection and setup
network connection and setup
Auto Network Setup
Run <IP Installer_v2.XX.exe> to display the camera search list.
At the initial startup, both [Auto Set] and [Manual Set] will be grayed out.
M
`
For cameras found with the IPv6 setting, these buttons will be grayed out as the cameras do not
support this function.
1. Select a camera in the search list.
Check the MAC address of the camera
on the camera’s label.
Both the [Auto Set] and [Manual Set]
buttons will be activated.
2. Click [Auto Set].
The Auto Setting dialog appears.
The <IP Address>, <Subnet Mask>,
and <Gateway> will be set automatically.
3. Enter the password.
Enter the password of “admin” account,
which was used to access the camera.
J
`
For the security purposes, you are
recommended to use a combination
of numbers, alphabets uppercase and
lowercase and special characters for your
password.
`
If you want to change the password, refer
to “Administrator password change” of
the user setup. (page 85)
4. Click [OK].
Auto network setup will be completed.
