5. Type in each item in the Port menu as necessary.
`
Neither the port range between 0 and 1023 nor port 3702 is available.
• HTTP : HTTP port used to access the camera via the web browser.
The default is 80(TCP).
`
Setting the HTTP port for Safari and Google Chrome browsers to 65535 is not allowed by security
policy.
• HTTPS : In this version, the security of the web communication protocol HTTP is
strengthened. It can be used when you set HTTPS mode in SSL.
The initial value is set to 443(TCP).
`
The available setting range is 1024~65535. (For security reasons, in your Safari or Google Chrome
browser, you may not use 65535 as your HTTPS port.)
• RTSP : Used to transfer videos in the RTSP mode; the default is 554.
• Use timeout : When connecting to RTSP, this function resets the connection if
there’s no response for a certain time.
• Device port : Set a port used to transfer video signals with the Samsung
protocols.
M
`
If changed the HTTP port, the browser exits.
Afterwards, address should contain the newly assigned HTTP port trailing the IP.
ex) IP address: 192.168.1.100, HTTP port : Assigned 8080
http://192.168.1.100:8080
(If HTTP port is set to 80, no need to specify the port number)
`
Using RTSP and HTTPS is recommended in order to prevent the image information from being
restored.
6. When done, click [Apply (
)].
Event setup
You can easily set the event detection items, and move to the detailed setting.
1. From the Setup menu, select the
<Basic (
)> tab.
2. Click <Event setup>.
3. Activate desired items on the Event list.
4. When done, click [Apply (
)].
M
`
To make detailed event settings, click on
your desired settings. Go to detailed <Event> setting.
English _89
● SETUP SCREEN
