ACCESSORIES
AV cable adapter
Remote controller
x1 x2 x1 x1
x1 x1 x1
Outer trim ring
Screw A (M5)
AV cable
Power supply cable
x1 x1 x1 x4
Screw B (M5)
x4
x4
x2 x1
Screw C (M4)
Sleeve
Self-lock connector
Front panel case
Release key Tapping screw
(M5 x 12)
Metal strap
Hexagonal bolt with
washer (M4 x 6)
Ta ke off the center console
Parking brake signal line
TO CONNECT THE PARKING BRAKE CONNECTOR CABLE (1)
Operation while driving is very dangerous. To protect customer safety, the operations while driving are
restricted. In order to judge driving or stopping, connect the parking brake connector cable. If parking
brake connector cable is not connected correctly, operations will be restricted while stopping as well as
driving.
* The parking brake signal line position varies depending on the vehicle model. Ask your auto dealer for details.
●When a parking brake is a hand brake type
(Example)
●When a parking brake is a foot brake type
(Example)
Parking brake signal line
¡Follow local rules and regulations for installing monitor.
¡Please contact your place of purchase if you have any questions about installation or connection.
t CAUTION
INSTALLATION
MANUAL
