IC & TRANSISTOR VOLTAGES
IC101 LA9241M
(V)
Pin No. 123456789101112131415
PLAY 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6
STOP 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5
Pin No. 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
PLAY 2.8 2.5 2.5 2.5 2.6 2.5 0 2.4 2.4 2.5 2.5 2.8 2.5 2.7 2.3
STOP 2.5 2.5 2.5 2.5 2.5 2.5 0 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.3
Pin No. 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45
PLAY 2.3 0 0 4.9 0 1.5 0 0 0 0.8 2.4 2.4 2.5 2.5 0
STOP 2.3 0 0 4.9 5.0 4.8 0 4.9 0 0 1.6 2.4 2.4 2.5 0
Pin No. 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
PLAY 2.5 2.5 0 0 2.3 4.5 0 0 4.9 0 5.0 2.5 2.5 2.5 2.6
STOP 2.5 2.5 0 0 2.3 4.8 4.8 0 0 0 5.0 2.5 2.5 0.9 0.9
Pin No. 61 62 63 64
PLAY 2.3 3.9 0 5.0
STOP 2.2 4.3 0 5.0
IC102 LC78622N
(V)
Pin No. 123456789101112131415
PLAY 0 0 1.6 0 1.6 5.0 0.3 0 2.5 2.5 0 0.9 0 0 0
STOP 00001.65.0002.52.40004.90
Pin No. 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
PLAY 1.7 0 5.0 0 0 2.4 5.0 5.0 4.9 1.5 0 0 1.8 0 0
STOP 4.9 4.9 4.9 0 0 2.4 0 4.9 4.8 2.4 0 0 2.4 0 4.9
Pin No. 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45
PLAY 2.4 00005.22.1002.15.205.02.02.0
STOP 2.4 0 0 0 4.9 5.2 2.1 0 0 2.1 5.2 4.9 4.9 2.0 2.0
Pin No. 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
PLAY 0 0.1 0 0.1 0 0.9 2.5 0.9 0 0 0 4.5 4.8 0 2.2
STOP 0 0.1 2.2 0 2.5 1.3 2.5 0 0 0 4.8 4.8 4.8 0 2.1
Pin No. 61 62 63 64
PLAY 2.2 0 0 0
STOP 2.2 0 0 0
IC103 LA6541
(V)
Pin No. 123456789101112131415
PLAY 8.3 0 2.7 2.5 4.1 3.5 3.5 4.1 2.5 2.7 5.0 7.7 5.0 5.0 2.6
STOP 8.6 4.8 2.5 2.5 2.5 3.9 3.8 4.0 2.5 2.5 5.0 7.8 5.0 5.0 2.5
Pin No. 16 17 18 19 20 21 22 23 24
PLAY 6.3 3.8 3.9 3.8 3.9 2.5 2.5 2.5 8.4
STOP 2.5 3.9 3.9 3.9 3.8 2.5 2.5 2.5 8.4
IC131 TA7291S
(V)
Pin No. 123456789
DR-OPEN 4.8 11.5 7.4 0 0 11.0 0.7 6.7 0
DR-CLOSE 0 11.5 0.7 0 0 11.0 7.4 6.7 4.8
STOP 4.8 11.5 0.6 0 0 11.4 0.6 6.7 4.8
IC132 TA7291S
(V)
Pin No. 123456789
CA-OPEN 0 11.5 0.7 0 0 11.0 6.3 5.6 4.8
CA-CLOSE 4.8 11.5 6.3 0 0 11.0 0.7 5.6 0
STOP 4.8 11.5 0.6 0 0 11.4 0.6 5.6 4.8
TRANSISTORS
PIN Q1301 Q1401
NAME B C E B C E
PLAY 4.5 1.9 3.9 8.2 5.0 5.0
STOP 4.9 1.6 4.3 8.3 5.0 7.7
