- 8 -
PARTS LIST
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN BE OF
SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE REPLACEMENT PARTS DESIGNATED,
OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN THE PARTS LIST
IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
614 310 6234 CARTON CASE
614 308 7663 CUSHION,TOP
614 308 7670 CUSHION,BOTTOM
614 271 6656 CUSHION,SET
614 310 6241 INSTRUCTION MANUAL
614 312 3231 INSTRUCTION MANUAL,GREEK
645 005 1227 ASSY,ANTENA,LOOP
614 308 5515 ANT,FM ANT
or 614 229 4635 ANT,FM ANT
645 034 1571 REMOCON,RB-C30ARD,SANYO
645 035 8098 BATTERY COVER,SERVICE PARTS
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 308 7335 DEC,WINDOW,CAS,L
2 614 308 7342 DEC,WINDOW,CAS,R
3 614 310 6081 LID,CASSETTE,L,AUTO REVERSE
4 614 308 7410 LID,CASSETTE,R
5 614 308 7526 SPRING,WIRE,LID CASSETTE L
6 614 308 7533 SPRING,WIRE,LID CASSETTE R
7 614 308 7397 KNOB,ROTARY
8 614 308 7199 DEC,VOL
9 614 308 7205 DEC,BASS
10 614 312 1480 DEC,WINDOW,FL,BASS XPANDER
11 614 308 7212 DEC,CD,TRAY
12 614 310 6043 ASSY,CABINET,FRONT
13 614 289 1117 MOUNTING,BRACKET,
DECK MECHA BOTTOM
14 614 289 1100 MOUNTING,BRACKET,
DECK MECHA TOP
15 614 309 7969 ASSY,GEAR,(SESK)
16 614 308 7083 BUTTON,SOUND
17 614 308 7069 BUTTON,POWER
18 614 308 7076 BUTTON,CD,OPEN
20 614 308 7106 BUTTON,CLOCK
21 614 308 7137 BUTTON,REC
22 614 308 7168 BUTTON,FUNCTION
23 614 310 3820 BUTTON,TAPE,AUTO REVERSE
24 614 308 7090 BUTTON,BASS
25 614 308 7243 DEC,WINDOW,BASS
26 614 308 7489 REFLECTOR,BASS
27 614 308 7472 REFLECTOR,SOUND
28 614 308 7519 REFLECTOR,CD
29 614 308 7502 REFLECTOR,DISC
30 614 308 7298 DEC,WINDOW,CD,REW
31 614 308 7304 DEC,WINDOW,CD,FF
32 614 308 7267 DEC,WINDOW,DISC,1
33 614 308 7274 DEC,WINDOW,DISC,2
34 614 308 7281 DEC,WINDOW,DISC,3
REF.NO. PART NO. DESCRIPTION
35 614 308 7366 DEC,SHEET,DISC
36 614 308 7120 BUTTON,DISC
37 614 308 7151 BUTTON,MEMORY
38 614 308 7311 DEC,WINDOW,CD,PLAY
39 614 308 7328 DEC,WINDOW,CD,STOP
40 614 308 7373 DEC,SHEET,CD
41 614 308 7144 BUTTON,CD
42 614 301 6533 MOUNTING,CD,FRONT,
FRONT/CD MECHA
43 614 301 6526 MOUNTING,CD,RIGHT,
FRONT/CD MECHA
44 614 301 6519 MOUNTING,CD,LEFT,
FRONT/CD MECHA
45 614 300 3113 COVER PICK,CD PICK COVER
46 614 302 1834 MOUNTING,CD,REAR,
PANEL REAR/CD MECHA
47 614 302 1902 TERMINAL,ANT,PANEL REAR/ANT
48 614 309 8614 PANEL,REAR,CD MECHA
49 614 310 6470 ASSY,CABINET,AFTER BENDING
50 614 310 3868 PANEL,REAR
52 614 129 1901 FIXER,AC CORD
or 614 284 1884 FIXER,AC CORD
53 614 290 4954 ASSY,CABINET,BOTTOM
54 614 274 8190 LABEL,SAFETY,LASER
55 614 225 8569 STAND,MAIN PWB
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 021 3503 SCR S-TPG BIN 3X10,BOTTOM/FRONT
Y02 411 024 3708 SCR S-TPG PAN+FLG 2X6,
DECK MECHA/MOUNTING PWB
Y03 411 021 3503 SCR S-TPG BIN 3X10,DECK MECHA
Y04 412 003 1708 SPECIAL SCREW,GEAR CASSETTE
Y05 412 032 6408 SPECIAL SCREW,HEAD PHONE
Y07 614 129 9136 LUG,CN423 FIX
Y08 411 021 3503 SCR S-TPG BIN 3X10,FRONT PWB
Y09 411 021 3503 SCR S-TPG BIN 3X10,SUB PWB
Y10 411 021 3503 SCR S-TPG BIN 3X10,
MOUNTING CD FRONT
Y11 411 021 3503 SCR S-TPG BIN 3X10,
CD MECHA/COVERPICK
Y12 411 021 3503 SCR S-TPG BIN 3X10,
MOUNING FRONT/MOUNTING L
Y13 411 021 1806 SCR S-TPG BIN 2.6X10,
CD MECHA/MOUNTING L,R(SI
Y14 411 027 3101 SCR S-TPG BIN 3X8,CD PWB GRAND
Y15 411 021 3503 SCR S-TPG BIN 3X10,
CD MECHA/MOUNTING L,R(BT
Y16 411 021 3503 SCR S-TPG BIN 3X10,
CD MECHA/MOUNTING REAR
To Next Page
