Sanyo PLC-SW30 Service Manual

-26-
1 R-VIDEOCNT M62392FP 143
2G-VIDEOCNT M62392FP 143 Video Center Adjustment ( = R/G/B-V1)
3B-VIDEOCNT M62392FP 143
4 R-Sub-Bright L3E7070K0A 0
5 G-Sub-Bright L3E7070K0A 0 Sub-Bright Adjustment
6 B-Sub-Bright L3E7070K0A 0
7 R-Sub-Gain L3E7070K0A 550 560 540 530 ✻ Gain Adjustment [R]
8 G-Sub-Gain L3E7070K0A 550 560 540 530 ✻ Gain Adjustment [G]
9 B-Sub-Gain L3E7070K0A 530 550 540 530 ✻ Gain Adjustment [B]
10 REF-R M62392FP 190
11 REF-G M62392FP 190
12 REF-B M62392FP 190
13 BVCOM L3E6100D0A 130
14 GVCOM L3E6100D0A 130 ✻ Common Center Adjustment
15 RVCOM L3E6100D0A 130
16 G-Gamma-Shift L3E7070K0A 512 512 512 512 ✻ Gamma Adjustment
17 R-Gamma-Shift L3E7070K0A 512 512 512 512 ✻ White Balance Adjustment [R]
18 B-Gamma-Shift L3E7070K0A 512 512 512 512 ✻ White Balance Adjustment [B]
19 NRS-B M62393FP 153 NRS Adjustment (up side)
20 NRS-A M62392FP 35 NRS Adjustment (down side)
21 R-V2 M62392FP 163
22 G-V2 M62392FP 163 Video Center Adjustment (Link to Item No.1-3)
23 B-V2 M62392FP 163
24 SubBright PW168 128 128 128 128
25 SubColor PW168 85 85 85 N/A
26 SubTint PW168 128 128 128 N/A
27 - 0
28 SubBright (Video) VPC3230 N/A Note 1 N/A 128 127 Note 1: 575i = the same as PAL
29 SubCont (Video) VPC3230 N/A Note 1 N/A 50 49
30 SubColor (Video) VPC3230 N/A Note 1 N/A 2070 2070
31 SubTint (Video) VPC3230 N/A Note 1 N/A 512 512
32 SubBright (480i,575i) VPC3230 N/A 199 N/A 196 197
33 SubCont (480i,575i) VPC3230 N/A 25 N/A 25 26
34 SubColor (480i,575i) VPC3230 N/A 31 N/A 23 23 Note 2: 480i = the same as NTSC
35 SubColor (480i,575i) VPC3230 N/A Note 2 N/A 29 29 575i = the same as PAL
36 - 0
37 V-Line Color Shading Correction Setting (R1) L3E7070K0A 2 Vertical Line Color Shading Correction
38 V-Line Color Shading Correction Setting (R2) L3E7070K0A 1
39 V-Line Color Shading Correction Setting (R3) L3E7070K0A 254
40 V-Line Color Shading Correction Setting (G1) L3E7070K0A 2
41 V-Line Color Shading Correction Setting (G2) L3E7070K0A 1
42 V-Line Color Shading Correction Setting (G3) L3E7070K0A 254
43 V-Line Color Shading Correction Setting (B1) L3E7070K0A 2
44 V-Line Color Shading Correction Setting (B2) L3E7070K0A 1
45 V-Line Color Shading Correction Setting (B3) L3E7070K0A 254
46 R-Reference voltage (H) L3E7070K0A 0
47 R-Reference voltage (L) L3E7070K0A 0
48 G-Reference voltage (H) L3E7070K0A 0
49 G-Reference voltage (L) L3E7070K0A 0
50 B-Reference voltage (H) L3E7070K0A 0
51 B-Reference voltage (L) L3E7070K0A 0
52 Color Shading Correction ON/OFF L3E7070K0A 1
53 Lamp Life Time 0 Read only
54 Baud Rate 10:9600 / 1: 19200 / 2: 38400
55 Shoot Out Mode 0 0: Normal / 1: Shoot out 1
56 Forced NOBRAND 0 0: Normal / 1: NOBRAND
FAN CONTROL Range
60 Fan Control SW 0 0-1 0: Auto / 1: manual
61 Fan Min. control (Fan 1) 97 70-210
62 Fan Min. control (Fan 2) 118 70-210
Initial
ItemNo. Name Device PC YCbCr Video Detail
480i(+) 480p(+) NTSC PAL Note: 480i(+) = 480i & 575i, 480p(+) = 480p & HDTV
● Service Adjustment Data Table
These initial values are the reference data written from the CPU
ROM to memory IC when replaced new memory IC. The adjust-
ment items indicated with “✻” are required to readjust following
to the “Electrical adjustments”. Other items should be used with
the initial data value.
Electrical Adjustments

Sanyo PLC-SW30 Specifications

General

Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	3LCD
Contrast ratio (typical)	300:1
Screen size compatibility	34 - 200 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	20 °
Lamp type	UHP
Lamp power	150 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	2500 h
RMS rated power	0.8 W
Number of built-in speakers	1
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Power consumption (typical)	244 W
Power consumption (PowerSave)	169 W
Focus	Manual
Throw ratio	1.6 - 1.9:1
Focal length range	- mm
Aperture range (F-F)	1.6 - 1.8
HDCP	-
Noise level	- dB
Dot clock scanning frequency	100 MHz
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	800 x 600 (SVGA)
USB connector type	USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	190 mm
Width	270 mm
Height	78 mm
Weight	2100 g
