Sanyo PLC-SW30 Service Manual

4
■ Specifications
● The specifications are subject to change without notice.
This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety stan-
dards against risk of fire, casualty and electrical hazards.
Projector Type Multi-media Projector
Dimensions (W x H x D) 10.63” x 3.07” x 7.48” (270mm x 78mm x 190mm) (not including Adjustable Feet)
Net Weight 4.6 lbs (2.1 kg)
LCD Panel System 0.5” TFT Active Matrix type, 3 panels
Panel Resolution 800 x 600 dots
Number of Pixels 1,440,000 (800 x 600 x 3 panels)
Color System PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N
High Definition TV SIgnal 480i, 480p, 575i, 575p, 720p, 1035i and 1080i
Scanning Frequency H-sync. 15 ~ 80 kHz, V-sync. 50 ~ 100 Hz
Projection Image Size (Diagonal) Adjustable from 34” to 200”
Projection Lens F 1.6 ~ 1.8 lens with f 18.3 mm ~ 21.9 mm with manual zoom and focus
Throw Distance 4.3’ ~ 21.2’ (1.3 m ~ 6.5 m)
Projection Lamp 160 W
Video Input Jack RCA Type x 1 (Video) and and Mini DIN 4 pin x 1 (S-Video)
AV Audio Input Jack Mini Jack (stereo) x 1
Computer Input Terminal (VGA) HDB 15 Terminal x 1
Computer Audio Input Jack Mini Jack (stereo) x 1
Control Port Connector Mini DIN 8 pin x 1
USB Connector USB Series B receptacle x 1
Internal Audio Amp 0.8 W RMS
Build-in Speaker 1 speaker, ø1.3" (32 mm)
Feet Adjustment 0˚ to 8.0˚
Voltage and AC 100 ~ 120V (2.4A Max. Ampere), 50/60Hz (The U.S.A and Canada)
Power Consumption AC 200 ~ 240V (1.2A Max. Ampere), 50/60Hz (Continental Europe and The U.K.)
Operating Temperature 41 ˚F ~ 95 ˚F (5˚C ~ 35˚C)
Storage Temperature 14 ˚F ~ 140 ˚F (-10˚C ~ 60˚C)
Remote Control Unit Wireless Remote Control, batteries AAA, SUM-04 or R03 type x 2
Presentation Remote Control, batteries AAA, SUM-04 or R03 type x 2
Presentation Remote Receiver
The CE Mark is a Directive conformity mark of the European Community (EC).

Sanyo PLC-SW30 Specifications

General

Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	3LCD
Contrast ratio (typical)	300:1
Screen size compatibility	34 - 200 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	20 °
Lamp type	UHP
Lamp power	150 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	2500 h
RMS rated power	0.8 W
Number of built-in speakers	1
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Power consumption (typical)	244 W
Power consumption (PowerSave)	169 W
Focus	Manual
Throw ratio	1.6 - 1.9:1
Focal length range	- mm
Aperture range (F-F)	1.6 - 1.8
HDCP	-
Noise level	- dB
Dot clock scanning frequency	100 MHz
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	800 x 600 (SVGA)
USB connector type	USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	190 mm
Width	270 mm
Height	78 mm
Weight	2100 g
