Sanyo PLC-SW30 Service Manual

-32-
IC9401
DIGITAL
TURBO
<LC24085>
IC301
CPU
FRC, CRC,
OSD
De-INTERLACE
<PW168A>
IC8201
A/D
<AD9883A>
IC5201
RGB SW /
SYNC SEP.
<AN5870>
IC101
DIGITAL
DECODER
<VPC3230>
IC5301
RGB_SYNC
<BA7078>
IC5302
YUV_SYNC
<TA1370>
IC501
B-LCD
DRIVER
<L3E06100>
IC531
G-LCD
DRIVER
<L3E06100>
IC561
R-LCD
DRIVER
<L3E06100>
IC3521
NRS
BUFFER
<LM7171>
IC3531
NRS
BUFFER
<LT1206>
B-LCD
PANEL
G-LCD
PANEL
R-LCD
PANEL
SCLK/SDATA
TP2531
TP2561
K25RK25GK25B
GR
GG
GB
+ +
IC401
COLOR
SHADING
CORRECTION
<L3E07070>
IC3531
NRS_SW
<4053>
K10D
K50A
K10E
K50B
COMPUTER IN /
COMPONENT IN
VIDEOS_VIDEO
VY
VUV
G_SYNC
G_SYNC
480p,575p only
Other sources
H/V
H
RGB(SCART) YUV(480i, 575i)
RGB YUV
VIDEO
Y/C
GREF,GCOAST,GCLK,GFBK,CLAMP
GVS
IIC_2 IIC_1
VHS,VVS,VPEN,VFIELD,VCLK,VHDREN
IC5303
PC/AV_SW
S_SW
FILT_480p/575p
GVSGHS
DR
DG
DB
ROUT
GOUT
BOUT
RO
DHS,DVS,DCLK
TPR1
SCLK/SDATA
IC3561
DAC
<M62398>
IC3571
DAC
<M62398>
IC3551
DAC
<M62393>
IC1881
BUFFER
<74LCX541>
BO
GO
IIC_2 IIC_2 IIC_1
TPG1
TPB1
NRSA/NRSB R/G/B_V1/V2
CBAL_SW
FPRR,FPRG
14
5
15
18,19
14
-
19
FILT_480p/575p
IIC_2
H H
V V
3
26
13 11
5 9
6 8
16 28
3
11
2
12
TPGHS
TPGVS
TP6202B
TP6202G
TP6202R
TPVHS
TPVVS
MAIN BOARDAV BOARD
116 715,1420,19,18 13,12,11 4,6 29
Y/C
VIDEO
CV_S
H/V
2,5
SYSTEM_BUS
S_SW
● Video signal processing circuit and LCD panel driving circuit
Chassis Block Diagrams

Sanyo PLC-SW30 Specifications

General

Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	3LCD
Contrast ratio (typical)	300:1
Screen size compatibility	34 - 200 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	20 °
Lamp type	UHP
Lamp power	150 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	2500 h
RMS rated power	0.8 W
Number of built-in speakers	1
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Power consumption (typical)	244 W
Power consumption (PowerSave)	169 W
Focus	Manual
Throw ratio	1.6 - 1.9:1
Focal length range	- mm
Aperture range (F-F)	1.6 - 1.8
HDCP	-
Noise level	- dB
Dot clock scanning frequency	100 MHz
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	800 x 600 (SVGA)
USB connector type	USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	190 mm
Width	270 mm
Height	78 mm
Weight	2100 g
