Sanyo PLC-SW30 Service Manual

-27-
Electrical Adjustments
Range
63 Fan Min. control (Fan 3) 79 70-210
65 Fan Max. control (Fan 1) 205 70-210
66 Fan Max. control (Fan 2) 147 70-210
67 Fan Max. control (Fan 3) 205 70-210
69 Temp. Low ( Sensor 1) 28 10-100
70 Temp High (Sensor 1) 34 30-100
71 Temp. Error (Sensor 1) 40 30-100
72 Temp. Low ( Sensor 2) 43 10-100
73 Fan 2 Low Speed Cooling Time at the first half period 0 0-20 0: 20sec / 1: 22sec / ... / 20: 60sec
74 Fan 2 Low Speed Cooling Voltage at the first half period 62 70-210
75 Temp. High (Sensor 2) 41 30-100
76 Temp. Error (Sensor 2) 51 30-100
77 Temp. Error (Sensor 1-3) 30 10-100
78 Temp. Error Cooling TIme 3 0-15 0: always ON / 1: 30s / 2: 60s / ... / 15: 450s
79 Cooling Time 3 1-15 1: 30sec / 2: 60sec / ... / 15: 450sec
80 HighLand Mode 0 0-3 0: Auto / 1: ON Low / 2: ON Mid / 3: ON High
81 Fan1 Speed 205 Fan Speed at Manual Setting
82 Fan2 Speed 147
83 Fan3 Speed 205
84 Min. Temp. (Sensor 2) at temp. error (Sensor 1-2) 45 30-100
85 Normal Fan Mode 0 0-2 0: Auto / 1: manual / 2: HighLand Mode
86 Cooling Fan Mode 0
87 Service Fan Mode 0
VPC3230
90 Notch Filter Select VPC3230 N/A Note 1 N/A 3 3 Note 1: 480i = the same as NTSC
91 Diagonal Dot Reduction VPC3230 N/A Note 1 N/A 1 1 575i = the same as PAL
92 Horizontal Differential Gain VPC3230 N/A Note 1 N/A 3 3
93 Vertical Differential Gain VPC3230 N/A Note 1 N/A 0 0
94 Vertical Peaking Gain VPC3230 N/A Note 1 N/A 7 7
95 AFC other1 VPC3230 N/A Note 1 N/A 540 540
96 AFC other2 VPC3230 N/A Note 1 N/A 536 536
97 Horizontal Peaking Filter VPC3230 N/A Note 1 N/A 1 1
98 Peaking Gain VPC3230 N/A Note 1 N/A 2 2
99 Peaking Filter Coring Enable VPC3230 N/A Note 1 N/A 0 0
101 Horizontal Lowpass Filter VPC3230 N/A Note 1 N/A 1 1
102 Horizontal Lowpass Filter Chroma VPC3230 N/A Note 1 N/A 0 0
103 DOR VPC3230 N/A Note 1 N/A 0 0
104 COR VPC3230 N/A Note 1 N/A 0 0
105 SGAIN VPC3230 N/A Note 1 N/A 15 15
106 YC Delay VPC3230 N/A Note 1 N/A 62 62
ADC
272 REDGAIN AD9883 70 N/A 70 N/A N/A
273 GRNGAIN AD9883 70 N/A 70 N/A N/A
274 BLUGAIN AD9883 70 N/A 70 N/A N/A
275 REDOFST AD9883 60 N/A 60 N/A N/A ✻ Pedestal Adjustment [R]
276 GRNOFST AD9883 60 N/A 65 N/A N/A ✻ Pedestal Adjustment [G]
277 BLUOFST AD9883 65 N/A 65 N/A N/A ✻ Pedestal Adjustment [B]
278 Clamp Duration AD9883 N/A N/A
279 Clamp Placement AD9883 N/A N/A
281 RACLP M62399FP 0
282 GACLP M62399FP 0
283 BACLP M62399FP 0
FAN CONTROL 2
288 Eco Fan Max. Control (Fan 1) 170
289 Eco Fan Max. Control (Fan 2) 71
290 Eco Fan Max. Control (Fan 3) 130
291 DLY3.3V_ON 100
292 DLY5V_ON 100
293 Eco Fan Min. Control (Fan 1) 79
294 Eco Fan Min. Control (Fan 2) 62
295 Eco Fan Min. Control (Fan 3) 71
OverScan
297 Expand Ratio (Vertical) 60Hz PIXEL N/A 1 N/A Video and S-Video mode only.
298 Expand Ratio (Horizontal) 60Hz PIXEL N/A 17 N/A Progressive OFF
299 Position (Horizontal) 60Hz PIXEL N/A 513 N/A
Initial
ItemNo. Name Device PC YCbCr Video Detail
480i(+) 480p(+) NTSC PAL Note: 480i(+) = 480i & 575i, 480p(+) = 480p & HDTV

Sanyo PLC-SW30 Specifications

General

Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	3LCD
Contrast ratio (typical)	300:1
Screen size compatibility	34 - 200 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	20 °
Lamp type	UHP
Lamp power	150 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	2500 h
RMS rated power	0.8 W
Number of built-in speakers	1
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Power consumption (typical)	244 W
Power consumption (PowerSave)	169 W
Focus	Manual
Throw ratio	1.6 - 1.9:1
Focal length range	- mm
Aperture range (F-F)	1.6 - 1.8
HDCP	-
Noise level	- dB
Dot clock scanning frequency	100 MHz
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	800 x 600 (SVGA)
USB connector type	USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	190 mm
Width	270 mm
Height	78 mm
Weight	2100 g
