11
Part Names and Functions
Note:
To ensure safe operation, please observe the following precautions:
– Do not bend, drop, or expose the remote control to moisture or heat.
– For cleaning, use a soft dry cloth. Do not apply benzene, thinner, spray,
or any chemical material.
Remote Control
⑦
㉑
④
⑲
②
⑧
⑨
⑬
⑰
⑤
⑥
⑳
⑯
③
② AUTO SET button
Execute the setting of Auto setup (includes Input search, Auto PC adj.
and Auto Keystone functions) in the setting menu.
(pp.23, 45)
⑤ S-VIDEO button
Select the S-VIDEO input source. (p.37)
⑥ Point
buttons
– Select an item or adjust the value in the On-Screen Menu. (p.21)
– Pan the image in the Digital zoom +/- mode. (p.36)
⑬
MUTE button
Mute the sound. (p.24)
⑦ SCREEN button
Select a screen mode. (pp.26,35,43)
⑯ P-TIMER button
Operate the P-timer function. (p.26)
⑩ NO SHOW button
Temporarily turn off the image on the screen. (p.26)
⑰ LAMP button
Select a lamp mode. (pp.25, 55)
⑲ KEYSTONE button
Correct keystone distortion. (pp.23, 46)
⑳ SELECT button
– Execute the selected item. (p.21)
– Expand or compress the image in Digital zoom mode. (p.36)
⑧ MENU button
Open or close the On-Screen Menu. (p.21)
⑨ FREEZE button
Freeze the picture on the screen. (p.25)
⑫ VOLUME +/- buttons
Adjust the volume level. (p.24)
① ON/STAND-BY button
Turn the projector on or off. (pp.18-20)
③ COMPUTER 1/2 buttons
Select the COMPUTER 1 or COMPUTER 2 input source. (pp.27-28, 38)
⑪ D.ZOOM buttons
Zoom in and out the images. (pp.25, 36)
⑭ IMAGE button
Select the image mode. (pp.26,33,40)
㉑ COMPONENT button
Select the COMPONENT input source. (p.38)
④ VIDEO button
Select the VIDEO input source. (p.37)
⑱
⑱ INFO. button
Operate the information function. (p.60)
①
㉒
㉒ HDMI button
Select the HDMI input source. (pp.25,50)
⑩
⑫
⑪
⑭
⑮
⑮ PIP button
Operate the Picture In Picture function. (pp.25,51)
To Next Page
