– 15 –
SM830035
1
1. Specifications
1
1. Specifications
1-2 Major Component Specifications
(B) Outdoor Unit
Unit Model No. SPW-C253GH5
Source 220 - 230 - 240 V / 1 phase / 50 Hz
Controller P.C.B. Ass'y CR - C253GH5 (Microprocessor)
Control circuit fuse 250 V, 3.15 A
Compressor Rotary (Hermetic)
Model ..... number C - R221H5W
Source 220 - 240 V / 1 phase / 50 Hz
Nominal output W 2200
Compressor oil cc 1500
Coil resistance Ω C – R : 0.76 , R – S : 3.52
(Ambient temperature 25 °C) C – S : 2.76
Safety devices
Overload relay models Internal type
Operating temperature Open °C 160 ± 5
Close °C87± 11
Crank case heater 240V, 25 W
Refrigerant amount at shipment kg R22 - 3.0
High pressure switch ACB
-
1TB07
Set pressure OFF kg/cm
2
30
ON kg/cm
2
24 ± 2.0
Fan Propeller
Number...diameter mm 1 ..... ø460
Fan speeds 2 (AUTO)
Fan motor
Model KFC6T - 91C5P
Source 220 - 230 - 240 V / 1 phase / 50 Hz
No. of pole ..... rpm (230V, High / Med.) 6...772 / 376
Nominal output W 70
Coil resistance Ω WHT – BRN : 127.3 , VLT – YEL : 15.0
(Ambient temperature 20°C) WHT – VLT : 56.7 , YEL – PNK : 7.2
Safety device Internal type
Operating temperature Open °C 130 ± 8
Close °C79± 15
Run capacitor VAC, µF 440 V, 6 µF
Heat exchange
Coil Aluminium plate fin / Copper tube
Rows ..... fin pitch mm 2 ..... 2.0
Face area m
2
0.616
+ 2.0
+ 0.5
