SM830035
1. Specifications
1
1-3 Other Component Specifications
Unit model No. Indoor Unit Outdoor Unit
SPW-U253GH56 SPW-C253GH5, SPW-C253GH8
Power Transformer ATR - II215TB ATR - I65B
Rated
Primary V. Hz AC 230 V, 50 Hz AC 230 V, 50 Hz
Secondary 10.2V , 1.4 A 14 V , 0.4 A
14 V , 0.5 A —
Coil resistance Ω WHT – WHT :110 , BRN – BRN : 0.5 WHT – WHT : 300 , BRN – BRN : 2.2
RED – RED : 2.3
Thermal cut off temperature °C 145 145
Thermistor (Coil sensor) PBC - 41E - S36, PBC - 41E - S25, PBC - 41E-S4
Coil resistance kΩ –10 °C : 23.7 , 10 °C : 9.7
– 5 °C : 18.8 , 20 °C : 6.5
0 °C : 15.0 , 30 °C : 4.4
5 °C : 12.1 , 40 °C : 3.1
45 °C : 2.6
Thermistor (Room or coil sensor) KTEC - 35 - S6 PTC - 51H - S1
Coil resistance kΩ 0 °C : 16.5 , 40 °C : 2.7 60 °C : 13.8 , 90 °C : 5.1
5 °C : 12.8 , 45 °C : 2.2 70 °C : 9.7 , 100 °C : 3.8
10 °C : 10.0 , 50 °C : 1.8 75 °C : 8.2 , 110 °C : 2.8
20 °C : 6.3 , 55 °C : 1.5 80 °C : 7.0 , 120 °C : 2.2
30 °C : 4.0 , 85 °C : 5.9 , 130 °C : 1.7
Relay — FMCA - 1SZ607
Coil rated V — AC 220 - 240 V
Contact rating V.A — AC 440 V, 13 A
Coil resistance (at 25 °C) Ω — —
Solenoid control valve or coil
Solenoid control valve IKV - 24D12 CHV - 0201
Solenoid coil DKV - MOZS550E0 CHV - 01AJ504D1
Drain pump WP20SL - 9 —
Rated AC 230 V, 14.7 W —
Float switch FS - 3502 - 202 —
Rated (Contact rated) AC 230 V, 50 W —
