Schenker SMART 60 User Manual

4 – MOUNTING AND INSTALLATION COD: 60S12/24.B.2021
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia - ALL RIGHTS RESERVED
26
4.5.2 Electric connections: wires (SMART 60 12/24V DC)
The 12/24 V power supply, from the service batteries, must be connected to the +/- clamps on the card of the
computer box. A 32 Ampere automatic circuit breaker for 12V systems must be installed on the power supply,
while a 16 Ampere for 24V systems.
The connection must be suitable to take the typical electric load (250Watt continuous).
The power supply cable section is related to the length of the cable. See the diagram of the recommended
sections below.
Voltage
Automatic
Cable lenght
switch
up to 3 mts
3 - 7 mt.
7-10 mt.
Volt
Ampere
mm2
AWG
mm2
AWG
mm2
AWG
12
32
10
7
16
5
25
3
24
16
4
11
4
11
6
9
The connection diagram in the computer box is the following:
Clamp connect to cable section
- Negative battery see table
+ Positive battery see table
EV Electrovalve (on the AC filter) 2.5 mm2
EV Electrovalve (on the AC filter) 2.5 mm2
A Remote panel 0.22 mm2
B Remote panel 0.22 mm2
12 Remote panel 0.50 mm2
- Remote panel 0.50 mm2
The microswitches allow the direct command of the pumps and of the electrovalve. They can be used as an
emergency solution for activating the watermaker. They have to be switched off in normal condition.
The rated current of the fuse is 400mA.
