occur due to a failure to observe this manual and the
2. Device description
1 Machine head
2 Base frame
3 Legs
4 Water tub
5 Workpiece support
6 Transverse cutting gauge
7 Angled stop
8 Guide rails
9 Cutting disc protection
10 Diamond cutting-disc
11
12 Star knob screw for angle adjustment
13 Cooling water pump
14
15 Motor
16 ON/OFF switch
17 Angle scale
18 Table extension
3. Technical data
1560 x 440 x 1140mm /
1845 x 440 x 1155mm
Cutting table
400 x 1290 /
400 x 1377 mm
30,0 l / 40,0 l
Weight 50 / 57 kg
Max. cutting length 920 / 1200 mm
Max. diagonal cutting
length
650 x 650 / 850 x 850
mm
Max 90° cutting height 36 / 40 mm
Max. 45° cutting height 29 / 34 mm
Motor
Power intake 900 / 1200 W
Motor speed 3000 1/min
Insulating material class F
IP54
Technical changes reserved!
Noise characteristic values
Noise at the workplace can exceed 85 dB (A). In this
the user (wear hearing protection!).
Noise output in dB
Sound power level of L
WA
= 86 dB (A)
Noise pressure level L
PA
= 72 dB (A)
1. Introduction
Manufacturer:
scheppach
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
and success.
Note:
-
ufacturer of this device will not be liable for damages
device in the following cases:
• Improper handling,
• Non-observation of the operating instructions,
•
• Installation and replacement with non-original
spare parts,
• -
•
VDE clauses 0100, DIN 57113 / VDE0113.
We recommend:
Read through the complete text in the operating in-
structions before installing and commissioning the
device. The operating instructions are intended to
help the user to become familiar with the machine
and take advantage of its application possibilities in
accordance with the recommendations. The operat-
ing instructions contain important information on how
-
service life of the machine.
-
-
age with the machine at all times and store it in a
plastic cover to protect it from dirt and moisture. Read
the instruction manual each time before operating the
-
-
structed concerning the operation of the machine and
who are informed about the associated dangers. The
minimum age requirement must be complied with.
woodworking machines must also be observed.
