Damaged electric connecting cables
-
necting cables.
The reasons are:
• Pressure points, if connecting cables are routed
through window or door gaps.
• Kinks due to improper mounting or routing of con-
necting cables.
• Intersections due to overruns of connecting cables.
• Insulation damage due to pulling out from wall
sockets.
• Cracks due to ageing of insulation.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage
-
connected from electrical power when checking for
damage.
-
nection cables of the same designation.
-
AC motor 230 V/ 50 Hz
•
• Mains connection and extension cable must have
3-wires = P + N + SL. - (1/N/PE).
• Extension cables must have a minimum cross-sec-
tion of 1.5 mm².
• The mains connection is secured with a max. 16A
fuse.
Start-up of the leakage current circuit-breaker:
• The function should be checked before each start-
• If the leakage current circuit-breaker does not
-
sonal protection! The device must therefore be
•
claims will become null and void. We do not accept
• Check the product for damage before each use! If
• After actuating the orange Reset button, the device
the triggering with the help of the Test button (as
described in “Operation”).
• Insert the leakage current circuit-breaker into the
socket.
• Press the orange Reset button.
2. Angle the guide rails (8) 45° to the left on the an-
gle scale (17).
3 Re-tighten the star knob screw (E) on both sides.
4 Perform cutting as described.
Replacing the diamond cutting wheel (Fig. 10 - 12)
Attention! Pull out the mains plug
1. Unscrew the screw (F) and remove the cutting
wheel guard (9). (Fig.10)
2.
hold.
3.
the direction in which the cutting wheel (10) runs.
(Left-handed thread)
4.
wheel (10).
5.
the new cutting wheel.
6. Insert the new cutting wheel in the reverse se-
quence and tighten. Attention: Ensure that the
cutting wheel runs in the correct direction!
7. Re-install the cutting wheel guard (9).
Setting the parallel position of the diamond cut-
ting disc (Fig. 13 - 15)
If the cut is not straight or the tile breaks along the
cutting line, the parallel position of the diamond cut-
ting disc must be set.
1. At the beginning, the stop rail must be positioned
square to the guide rail. For this, loosen the Allen
screws (A) along the stop rail and align it square
with a carpenter’s square or a large tile. In this
step, the diamond cutting disc must run along the
entire length of the square or the tile edge. After-
wards, re-tighten the two stop rail Allen screws
(A).
2.
two Phillips screws (B). (Fig. 16)
3. Disassemble the cable retainers (C). (Fig. 17)
4.
the saw unit sides. (Fig. 18, 19)
5. Now the entire saw unit with diamond cutting disc
can be aligned to the stop rail using a carpenter’s
square or a large tile. (Fig. 20)
6. Re-tighten the saw unit’s hexagon nuts and as-
semble all machine components. Check it is par-
11. Electric connection
The electric motor installed is connected and
ready for operation. The connection complies
with the applicable VDE and DIN provisions. The
customer‘s mains connection as well as the ex-
tension cable used must also comply with these
regulations.
