www.scheppach.com / service@scheppach.com / +(49)-08223-4002-99 / +(49)-08223-4002-58
22
|
GB
2. Device description (Fig. A)
1 Vibratory plate
2 Eccentric
3 Drive
4 Motor
5 Gasoline tank
6 Air lter
7 Exhaust pipe
8 Lower handle
9 Upper handle
10 Gas lever
3. Technical data
HP1100S HP1300S
Motor / Engine 1-cylin-
der-4-stroke
for unleaded
gasoline
1-cylin-
der-4-stroke
for unleaded
gasoline
Displacement 196 cm³ 196 cm³
Motor power 4,1 kW 4,1 kW
Tank volume 3,6 l 3,6 l
Motoroil volume max. 0,6l max. 0,6l
Exciter oil volume 0,08 l 0,1 l
Working plate size
(LxW)
aprox. 530 x
350 mm
aprox. 540 x
420 mm
Compaction
pressure
11 kN 13 kN
Travel Speed 25 m/min 15 m/min
Vibration strokes 5500 vpm 5500 vpm
Compaction
Depth
25 cm 30 cm
Max. permissible
angle of the motor
20° 20°
Weight aprox. 57 kg aprox. 82,5 kg
Subject to technical modications!
Noise & vibration
m Warning: Noise can have serious effects on
your health. If the machine noise exceeds 85 dB (A),
please wear suitable hearing protection.
Noise characteristic values
Sound power level L
WA
: 103,3 dB (A)
Sound pressure level L
pA
: 77,3 dB (A)
Uncertainty K
wa/pA
: 2,58 dB (A)
Vibration characteristics
HP1100S HP1300S
Vibration a
h
10,8 m/s² 15,6 m/s²
Uncertainty K
wa/pA
1,5 m/s² 1,5 m/s²
1. Introduction
MANUFACTURER:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
DEAR CUSTOMER
We hope your new tool brings you much enjoyment
and success.
NOTE:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specied.
We recommend:
Read through the complete text in the operating in-
structions before installing and commissioning the
device. The operating instructions are intended to
help the user to become familiar with the machine
and take advantage of its application possibilities in
accordance with the recommendations. The operat-
ing instructions contain important information on how
to operate the machine safely, professionally and
economically, how to avoid danger, costly repairs, re-
duce downtimes and how to increase reliability and
service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regu-
lations that apply for the operation of the machine in
your country. Keep the operating instructions pack-
age with the machine at all times and store it in a
plastic cover to protect it from dirt and moisture. Read
the instruction manual each time before operating the
machine and carefully follow its information. The ma-
chine can only be operated by persons who were in-
structed concerning the operation of the machine and
who are informed about the associated dangers. The
minimum age requirement must be complied with
In addition to the safety instructions in this operating
manual and the separate regulations of your coun-
try, the generally recognised technical rules relating
to the operation of such machines must also be ob-
served.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
