Servonaut M24 User Manual

34
Controls assignment for Graupner Nautic Expert
Sound module, speed controller/light set and multiswitch via multi channel
Typ SM7 M24
MM4
a/1 Pushbutton Indicator L/R
b/2 Pushbutton
Parking/
driving
c/3 Pushbutton
Output L1 & S2, wiper func-
tion servo output 2
d/4 3-Switch Gearshifting
Servo output 1 only usable
without cruise control
e/5 3-Switch
Dumper/
Martin Horn
f/6 3-Switch Volume
g/7
Pushb.-
Switch
Hazard lights
Output S3 not usable
Output L4 e.g. high beam
h/8
Pushb.-
Switch
Starter/Horn
M24
