11
LC-24LE210
LC-24LE220
REMOVING OF MAJOR PARTS
Stand
Rear Cabinet
Front Cabinet
4
5
3
2
1. To slacken the 4 lock screws and detach the Stand.
2. Remove the 2 lock screws , 2 lock screws , 3 lock screws , 1 lock screw and detach the Rear Cabinet
1
3
2
4
5
