Sharp LC-24LE210E Service Manual

18
LC-24LE210
LC-24LE220
Page Line Sub
Page
Item Description Remarks (adjustment details, etc.)
01/17 [SHARP FACTORY MENU
1 Main Version 24LE210E SHARP v1.12 SEES
v94 MSTAR CL308413
Informative only (Main microprocessor version)
2 Bootloader Version BD_MST064E_C01A 2 Informative only
3 Normal Standby Cause
No signal Informative only
4 Error Standby Cause None Informative only
5 INIT Factory Init Submenu Press “OK” to enter to Factory Init Submenu
02/17 Factory Init EURO I
nformative (EURO/RUSSIA/SWEDEN/UK/EAST EUROPE)
Inch Setting CMO_M236H3-LA2 Panel type
Center Acutime 0 H 0 M Backlight ON accumulated Time
RESET
Press “◄ “ or “ ►” to reset Center Acutime
6 ADJUST QMAP ADJUST Submenu Press “OK” to enter to QMAP ADJUST Submenu
03/17 INPUT SOURCE (1/6) RF_PAL_BGHI
AFEC Only for Engineering purpose (Please don’t use)
Comb Only for Engineering purpose (Please don’t use)
SECAM Only for Engineering purpose (Please don’t use)
SCinit Only for Engineering purpose (Please don’t use)
CSC OFF Only for Engineering purpose (Please don’t use)
CSC_Dither OFF Only for Engineering purpose (Please don’t use)
YCdelay OFF Only for Engineering purpose (Please don’t use)
PreFilter OFF Only for Engineering purpose (Please don’t use)
HSD_Y ALL PASS1X Only for Engineering purpose (Please don’t use)
HSD_C ALL PASS1X Only for Engineering purpose (Please don’t use)
VSD OFF Only for Engineering purpose (Please don’t use)
CTI CTI_1 Only for Engineering purpose (Please don’t use)
04/17 INPUT SOURCE (2/6) DTV/ RF/Multimedia ...
MemFormat 422MF Only for Engineering purpose (Please don’t use)
444To422 ON Only for Engineering purpose (Please don’t use)
PreSNR OFF Only for Engineering purpose (Please don’t use)
DNR NR_OFF Only for Engineering purpose (Please don’t use)
DNR_Motion MR_NR Only for Engineering purpose (Please don’t use)
DNR_Y OFF Only for Engineering purpose (Please don’t use)
DNR_MED OFF Only for Engineering purpose (Please don’t use)
DNR_C OFF Only for Engineering purpose (Please don’t use)
PNR OFF Only for Engineering purpose (Please don’t use)
PNR_Y OFF Only for Engineering purpose (Please don’t use)
PNR_C OFF Only for Engineering purpose (Please don’t use)
PostCCS OFF Only for Engineering purpose (Please don’t use)
05/17 INPUT SOURCE (3/6) DTV/ RF/Multimedia ...
PostCCS_Smooth PCS_6 Only for Engineering purpose (Please don’t use)
420CUP OFF Only for Engineering purpose (Please don’t use)
MADi P_MODE_MOT10 Only for Engineering purpose (Please don’t use)
MADi_Motion MOT_PMODE Only for Engineering purpose (Please don’t use)
MADi_ADP3x3 OFF Only for Engineering purpose (Please don’t use)
MADi_MORPHO OFF Only for Engineering purpose (Please don’t use)
MADi_DFK OFF Only for Engineering purpose (Please don’t use)
