Sharp LC-24LE210E Service Manual

39
LC-24LE210
LC-24LE220
2.3. IC 1001 (MSD3303GX)
2.3.3. Pin Description (continued)
2. Detailed ICs Information, DUNTKF639WE (Main Unit) (continued)
DVI/HDMI Interface
Pin Name Pin Type Function Pin
RXACKN DVI/HDMI Input Negative DVI/HDMI Input for A Link Clock Channel F2
RXACKP DVI/HDMI Input Positive DVI/HDMI Input for A Link Clock Channel F1
RXA0N DVI/HDMI Input Negative DVI/HDMI Input for A Link Data Channel 0 G3
RXA0P DVI/HDMI Input Positive DVI/HDMI Input for A Link Data Channel 0 G2
RXA1N DVI/HDMI Input Negative DVI/HDMI Input for A Link Data Channel 1 G1
RXA1P DVI/HDMI Input Positive DVI/HDMI Input for A Link Data Channel 1 H3
RXA2N DVI/HDMI Input Negative DVI/HDMI Input for A Link Data Channel 2 H2
RXA2P DVI/HDMI Input Positive DVI/HDMI Input for A Link Data Channel 2 H1
RXBCKN DVI/HDMI Input Negative DVI/HDMI Input for B Link Clock Channel B1
RXBCKP DVI/HDMI Input Positive DVI/HDMI Input for B Link Clock Channel C3
RXB0N DVI/HDMI Input Negative DVI/HDMI Input for B Link Data Channel 0 C2
RXB0P DVI/HDMI Input Positive DVI/HDMI Input for B Link Data Channel 0 C1
RXB1N DVI/HDMI Input Negative DVI/HDMI Input for B Link Data Channel 1 D3
RXB1P DVI/HDMI Input Positive DVI/HDMI Input for B Link Data Channel 1 D2
RXB2N DVI/HDMI Input Negative DVI/HDMI Input for B Link Data Channel 2 D1
RXB2P DVI/HDMI Input Positive DVI/HDMI Input for B Link Data Channel 2 E3
RXCCKN DVI/HDMI Input Negative DVI/HDMI Input for C Link Clock Channel AC8
RXCCKP DVI/HDMI Input Positive DVI/HDMI Input for C Link Clock Channel AD8
RXC0N DVI/HDMI Input Negative DVI/HDMI Input for C Link Data Channel 0 AE8
RXC0P DVI/HDMI Input Positive DVI/HDMI Input for C Link Data Channel 0 AC9
RXC1N DVI/HDMI Input Negative DVI/HDMI Input for C Link Data Channel 1 AD9
RXC1P DVI/HDMI Input Positive DVI/HDMI Input for C Link Data Channel 1 AE9
RXC2N DVI/HDMI Input Negative DVI/HDMI Input for C Link Data Channel 2 AD10
RXC2P DVI/HDMI Input Positive DVI/HDMI Input for C Link Data Channel 2 AE10
SOURCE OF DOCUMENTATION
IC201 (MSB1220) LE210 Series
MSTAR Semiconductor: Preliminary Product Brief Version 0.1.
Low Power DVB-T Demodulator.
Doc. No.: msb1220_pb_v01. January 2009.
IC201 (MSB1222) LE220 Series
MSTAR Semiconductor: Preliminary Product Brief Version 0.1.
Low Power DVB-T/C Demodulator.
Doc. No.: msb1222_pb_v01. January 2009.
IC 306 (MSH 9000-LF)
MSTAR Semiconductor; Preliminary Product Brief Version 0.3.
Power Management IC.
Doc. No.: MSH9000_pb_v03. April 2009.
IC1001 (MSD3303GX)
MSTAR Semiconductor; Preliminary Pin Diagram and Description. Version 0.2.
DVB LCD/PDP DTV Processor.
Doc. No.: MSD3303GX_pin_v02 . April 2009.
MSTAR Semiconductor; Block Diagram. Version 0.1.
All-in-one DTV Processor.
Doc. No.: MSD3303GX_bd_v01. April 2009.
