Connecting a PC
Commands
• Commands not indicated here are not guaranteed to operate.
NOTE
• If an underbar (_) appears in the parameter column, enter a space.
• If an asterisk (*) appears, enter a value in the range indicated in
brackets under CONTROL CONTENTS.
PC compatibility chart
RS-232C commands list
Power Management is a registered trademark of Sun Microsystems, Inc.
VGA and XGA are registered trademarks of International Business Machines Corp.
Resolution Horizontal Frequency Vertical Frequency Analogue (D-Sub)
Digital (HDMI) VESA Standard
VGA
640 g 480
31.5 kHz 60 Hz
✔✔✔
SVGA
800 g 600
37.9 kHz 60 Hz
✔✔✔
XGA
1024 g 768
48.4 kHz 60 Hz
✔✔✔
WXGA
1360 g 768
47.7 kHz 60 Hz
✔✔✔
SXGA
1280 g 1024
64.0 kHz 60 Hz
✔✔✔
SXGA+
1400 g1050
65.3 kHz 60 Hz
✔✔✔
UXGA
1600 g1200
75.0 kHz 60 Hz
✔✔✔
1080p
1920 g1080
67.5 kHz 60 Hz
✔✔
—
NOTE
• This TV has only limited PC compatibility, correct operation can only be guaranteed if the video card conforms exactly to the VESA 60Hz
standard. Any variations from this standard will result in picture distortions.
CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS
POWER SETTING P O W R 0 _ _ _ POWER OFF (STANDBY)
INPUT SELECTION I T G D _ _ _ _ INPUT SWITCHING (TOGGLE)
I T V D _ _ _ _ ATV (CHANNEL FIXED)
I D T V _ _ _ _ DTV (CHANNEL FIXED)
I A V D * _ _ _ INPUT1~7 (1-7)
CHANNEL D C C H * * _ _ TV DIRECT CHANNEL (1–99)
C H U P _ _ _ _ CHANNEL UP
C H D W _ _ _ _ CHANNEL DOWN
D T V D * * * _ DTV DIRECT CHANNEL (1-999)
D T U P _ _ _ _ DTV CHANNEL UP
D T D W _ _ _ _ DTV CHANNEL DOWN
AV MODE SELECTION A V M D 0 _ _ _ TOGGLE
A V M D 1 _ _ _ STANDARD
A V M D 2 _ _ _ MOVIE
A V M D 3 _ _ _ GAME
A V M D 4 _ _ _ USER
A V M D 5 _ _ _ DYNAMIC (Fixed)
A V M D 6 _ _ _ DYNAMIC
AVMD7__ _PC
A V M D 8 _ _ _ x.v.Colour
A V M D 1 0 0 _ AUTO
A V M D 1 4 _ _ STANDARD (3D)
A V M D 1 5 _ _ MOVIE (3D)
A V M D 1 6 _ _ GAME (3D)
VOLUME V O L M * * _ _ VOLUME (0–60)
POSITION H P O S * * * _ H-POSITION (AV) (
f
nn ~ nn)
H P O S * * * _ H-POSITION (PC) (
f
nn ~ nn)
V P O S * * * _ V-POSITION (AV) (
f
nn ~ nn)
V P O S * * * _ V-POSITION (PC) (
f
nn ~ nn)
C L C K * * * _ CLOCK (0–180)
P H S E * * * _ PHASE (0–40)
WIDE MODE W I D E 0 _ _ _ TOGGLE (AV)
W I D E 1 _ _ _ NORMAL (AV)
W I D E 2 _ _ _ ZOOM 14:9 (AV)
W I D E 3 _ _ _ PANORAMA (AV)
CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS
WIDE MODE W I D E 4 _ _ _ FULL (AV)
W I D E 5 _ _ _ CINEMA 16:9 (AV)
W I D E 6 _ _ _ CINEMA 14:9 (AV)
W I D E 7 _ _ _ NORMAL (PC)
W I D E 8 _ _ _ CINEMA (PC)
W I D E 9 _ _ _ FULL (PC)
W I D E 1 0 _ _ DOT BY DOT (AV/PC)
W I D E 1 1 _ _ UNDERSCAN (AV)
W I D E 1 2 _ _ AUTO (During playback USB/
Home network video only)
W I D E 1 3 _ _ ORIGINAL (During playback USB/
Home network video only)
MUTE M U T E 0 _ _ _ TOGGLE
M U T E 1 _ _ _ MUTE ON
M U T E 2 _ _ _ MUTE OFF
SURROUND A C S U 0 _ _ _ SURROUND TOGGLE
A C S U 1 _ _ _ SRS TS HD ON
A C S U 2 _ _ _ SURROUND OFF
A C S U 4 _ _ _ SURROUND 3D HALL
A C S U 5 _ _ _ SURROUND 3D MOVIE
A C S U 6 _ _ _ SURROUND 3D STANDARD
AUDIO CHANGE A C H A _ _ _ _ TOGGLE
SLEEP TIMER O F T M 0 _ _ _ OFF
O F T M 1 _ _ _ SLEEP TIMER 30 MIN
O F T M 2 _ _ _ SLEEP TIMER 1 HOUR
O F T M 3 _ _ _ SLEEP TIMER 1 HOUR 30 MIN
O F T M 4 _ _ _ SLEEP TIMER 2 HOUR
O F T M 5 _ _ _ SLEEP TIMER 2 HOUR 30 MIN
TEXT T E X T 0 _ _ _ TEXT OFF
T E X T 1 _ _ _ TEXT ON (TOGGLE)
D C P G * * * _ DIRECT PAGE JUMP (100-899)
3D T D C H 0 _ _ _ 3D OFF
TDCH1__ _
2D s 3D
T D C H 2 _ _ _ SIDE BY SIDE
T D C H 3 _ _ _ TOP AND BOTTOM
TDCH4__ _
3D s 2D (SIDE BY SIDE)
TDCH5__ _
3D s 2D (TOP AND BOTTOM)
T D C H 6 _ _ _ 3D AUTO
TDCH7__ _
3D s 2D
