Chapter
3
Technical Information
TiM55x/56x/57x ranging laser scanner
10
©
SICK AG · Germany · All rights reserved · Subject to
change without notice
8015883/YZK8/2016-07-07
Mounting
Placement of two TiM5xx with parallel offset
Placement of two TiM5xx with parallel offset, one of these upside down
Placement of two TiM5xx upside do
wn, parallel of
fset
Placement of two TiM5xx with parallel offset, one of these upside down
9
11
Table of Contents
1 About this Document
3
Table of Contents
5
2 Operating Principle of the Tim5Xx
6
Measurement Principle
6
Distance Measurement
6
Direction Measurement
6
3 Mounting
9
Notes on Mounting
9
Optional Accessories
11
4 Electrical Installation
14
Overview of All Interfaces
14
Pin and Wire Color Assignments
14
Notes on Electrical Installation
15
Prerequisites for Safe Operation of the Tim5Xx in a System
16
Installation Steps
19
5 Measured Value Output
21
Telegrams
21
Request Measured Values
22
Measured Value Output Fomat
24
6 License Texts
28
