Siemens FN2012-A1 User Manual

Wiring
Ethernet switch as a repeater
4
22 | 34
Building Technologies
A6V10407862_d_en_
--
Siemens Industry, Inc.
2018
-
09
-
07
Two repeaters
Figure 15: 2x Ethernet switch (modular) as a repeater in the electric Ethernet
Jumper settings on the VN2001 with two repeaters:
Switch/repeater VN2001 in port P1 VN2001 in port P0
Switch 1 Not connected PoE
Repeater 1 PoE Ground fault supervision
Repeater 2 Neutral position PoE
Switch 2 PoE Not connected
Guidelines
● Max. two repeaters between two nodes.
● Electric Ethernet distance between two nodes maximum 300 ft/100 m.
● Repeater power supply via 'Power over Ethernet' (PoE) from the VN2001.
● For each switch (node), 1 repeater can be supplied with power.
● The switch carries out ground fault supervision as far as the repeater.
● If there are two repeaters, the first one transfers ground fault supervision to the
second repeater.
MoNet
PMI & Mainboard
Ethernet
P2 P3 P4 P5
P0 P1
POWER
FAULT
MoNet
Panel
P2 P3 P4 P5
P0 P1
P
O
W
E
R
F
A
U
L
T
MoNet
P2 P3 P4
P5
P0 P1
P
O
W
E
R
F
A
U
L
T
MoNet
MoNet
PMI & Mainboard
Ethernet
P2
P3
P4
P5
P0
P1
P
O
W
E
R
F
A
U
L
T
MoNet
Panel
Electrical Ethernet
Repeater1
Repeater2
Switch1
Switch2
100 m 100 m 100 m
Ground fault
PoE & Ground fault
PoE
P1 P0
P1 P0
P1 P0
P1 P0
