Frei verwendbar House Control with Master-Slave - LOGO! Set 9
Entry ID: 64143308, V2.2, 09/2018
14
© Siemens AG
2018 All rights reserved
Function description
In manual mode, the lights can be controlled with buttons or with the cursor keys
over the LOGO! controller and the LOGO! TDE. In addition, the lights can be
controlled with a tablet, smartphone or PC with the F-keys over the integrated
webserver of LOGO! 8.
The panic mode is activated when one of the light buttons is pressed for at least
3 seconds. All lights are switched on.
The panic mode is deactivated when one of the light buttons is pressed for at least
3 seconds again. All lights are switched off.
The panic mode is automatically deactivated with a time delay of 30 minutes.
Table 2-12
No.
Function
Function block
Block name in the
program
1.
Switching lighting in room 1
Pulse relay
Light room 1
2.
Switching lighting in room 2
Pulse relay
Light room 1
3.
Switching the exterior lighting
Pulse relay
Outside light

Siemens LOGO! 8 Specifications

General

Model	LOGO! 8
Programming	LOGO! Soft Comfort
Memory	400 function blocks
Real-time clock	Yes
Protection class	IP20
Digital inputs	8 integrated
Digital outputs	4 integrated
Analog inputs	2 integrated
Communication	Ethernet
Supply Voltage	12/24V DC
Operating temperature	0 to 55 °C
