3 Installation and Commissioning
Frei verwendbar House Control with Master-Slave - LOGO! Set 9
Entry ID: 64143308, V2.2, 09/2018
© Siemens AG
2018 All rights reserved
3 Installation and Commissioning
This chapter describes the steps necessary to start up the example with the code
from the download and the hardware list.
3.1 Installing the hardware
3.1.1 LOGO! 8 and TDE
Please note the respective setup guidelines for LOGO! 8 and LOGO! TDE. Further
information is available in the LOGO! manual in chapter "LOGO! installation and
wiring”.
3.1.2 WLAN Access Point
Connect the WLAN Access Point to the network with your LOGO! devices via
Ethernet, e.g. via LOGO! CSM. Further information is available in the manual of the
WLAN Access Point.
Make sure that your WLAN Access Point and the LOGO! have the same basis
address. For example:
IP address master LOGO!: 192.168.1.10
IP address WLAN: 192.168.1.xxx
3.2 Installing the software
It is assumed that the necessary LOGO! Soft Comfort V8 software has been
installed on your PC and that you are familiar with the basic handling of this
software.
