17 / 22
Siemens Desigo Touch and Web CM111029en_04
Building Technologies Compatibility & limitations – System limits 2014-08-15
2.5.3 Supported graphics formats
The wide-screen format 2144 x 1112 pixels achieves the best results for the work
screen. If the image ratio is not correct, the image is adapted automatically to the
work screen. The ratio, however, is always the same.
Note: The work screen of both Desigo touch panels (PXM40 and PXM50) is
1072 x 556 pixels.
Format Description
png Recommended for plant diagram graphics
jpg For photos
, e.g. of the own building as home screen
gif For graphics without animation
svg Rendered by browsers, thus resulting in possible differences.
Inkscape is recommended as the tool to create graphics.
SVG exported from Microsoft Visio is not supported.
1)
The best results are achieved at the above resolution (2144 x 1112).
Special note: Compress photos from high-resolutions cameras.
General recommendation: Format png or jpg is the preferred format depend-
ing on the application, as this format allows for achieving best results relative to
resolution and min. memory requirements.
