7.3 Machine control panels
Table 7-2 Machine control panels
Safety
Safety class III; PELV according to EN 50178
Degree of protection accord‐
ing to
DIN EN 60529
Front side IP54 Rear side IP00
Approvals CE / UL
Electrical data
Input voltage 24 VDC
Power consumption, max. 2 W (without illuminated customer keys)
Mechanical data
Dimensions (mm) Width:
465.9
Height:
412.4
Depth
(without additive in‐
stallation ele‐
ments):
Milling MCP: 49
Turning MCP: 78
Weight 5 kg
Mechanical ambient condi‐
tions (with PCU)
Operation Transport
(in transport packaging)
Vibratory load 10 – 58 Hz: 0.075 mm
58 - 500 Hz: 9.8 m/s
2
according to EN 60721-3-3
5 – 58 Hz: 0.075 mm
58 - 500 Hz: 9.8 m/s
2
according to EN 60721-3-2
Shock load 50 m/s
2
, 30 ms,
100 shocks
according to DIN EN 60068-2-27
Climatic ambient conditions
Heat dissipation By natural convection
Moisture condensation and
ice formation
Not permissible
Supply air Without aggressive gases, dusts, and oils
Use and operation
Applicable standards EN 60721-3-3
Climate class Based on 3K3
Temperature limits 0 ... 40º C
Temperature change Max. 30 K/h
Limits for relative humidity 5 ... 90% / ≤ 25 g/m
3
Permissible change in the
relative air humidity
Max. 6%/h
Technical specifications
7.3 Machine control panels
ERGOline Stage 3
Manual, 02/2015, 6FC5397-4FP40-0BA0 47
