Spare parts
8
8.1 Overview
The table provides an overview of the spare parts available for the machine control panels.
Name Description Quantity Order number
Handwheel For turning machine control panel 1 6FC9320-5DM00
Feedrate / rapid tra‐
verse override
Electronic rotary switch 1x23G, T=32, cap, knob, pointer, rap‐
id traverse and feedrate dials
1 6FC5247-0AF13-1AA0
Feedrate / rapid tra‐
verse override
Electronic rotary switch 1x29G, T=32, cap, knob and pointer 1 6FC5247-0AF14-1AA0
Rotary knob Cap, knob and pointer for override rotary switch 10 6FC5248-0AF31-0AA0
Key caps with label
fields
- 90, ergo-gray
- 20 each of red/green/yellow/mid-gray
1 set 6FC5248-0AF12-0AA0
Labeled key caps For turning version 1 set 6FC5248-0AF25-0AA0
Labeled key caps For milling version 1 set 6FC5248-0AF26-0AA0
ERGOline Stage 3
Manual, 02/2015, 6FC5397-4FP40-0BA0 49
