Description
2
2.1 Overview
NOTICE
Observe the EMC-compatible installation of the components
The components provided by Siemens meet CE requirements. The customer is responsible
for ensuring that the components continue to meet the requirements once installed.
For user-friendly operation of the machine functions of milling and turning machines, you can
equip your operator panel with the following machine control panels:
● MCP 466C-M IE (milling)
● MCP 466C-T IE (turning)
Validity
The following description applies to the following components:
Designation Properties Order number
Monitor: SIMATIC IFP2200 MT OEM
1)
22" display, touch screen 6AV7466-8MC31-0MG0
PC: SIMATIC IPC627D OEM
2)
HD graphic onboard, 2 x GB Ethernet (IE/PN), 4 x
USB 3.0, time monitoring, temperature/fan monitoring
6BK1000-6MG00-1AA0
Machine control panel:
SINUMERIK MCP 466C-M IE
Milling
version, mechanical keys,
with rapid traverse and feedrate override
6FC5303-0AF50-3BB0
Machine control panel:
SINUMERIK MCP 466C-T IE
Turning
version, mechanical keys,
with handwheel and feedrate override
6FC5303-0AF50-4BB0
1)
This description refers to the differences to the SIMATIC IFP2200 Touch Extended standard device. You can find the
standard documentation in SIOS: http://support.automation.siemens.com/WW/view/en/65288650
2)
This description refers to the differences to the SIMATIC IPC627D standard device. You can find the standard
documentation in SIOS: http://support.automation.siemens.com/WW/view/en/87514734
Characteristics
IFP2200 MT OEM industrial monitor:
● 22" LCD widescreen display
● Touch operation
● LED backlight can be dimmed 100%
ERGOline Stage 3
Manual, 02/2015, 6FC5397-4FP40-0BA0 7
