Expanding and assigning parameters to the device
6.5 Installing expansion cards
SIMATIC IPC547G
78 Operating Instructions, 04/2020, A5E49948632-AA
6.5 Installing expansion cards
Note the following:
● Specification of the expansion cards
The device is designed for the following types of expansion cards:
– PCI specification 2.3
– PCIe Gen 2, expansion cards of the PCIe type Gen 1 and Gen 2 are supported.
– PCIe Gen 2, expansion cards of the PCIe type Gen 1, Gen 2, Gen 3 and PEG are
supported.
PCI expansion cards with 5 V and 3.3 V supply voltage can be operated.
The expansion cards must not exceed the specified dimensions. If the height is
exceeded, you may experience contact problems, malfunctions and difficulties with the
assembly.
You can find the permitted dimensions for expansion cards in the chapter "Dimension
drawing of the expansion cards (Page 147)".
Note
Output is limited for PCI expansion cards with 5 V supply voltage. The total power
consumption of the expansion ca
rds must be ≤ 25 W.
● Long PCI/PCIe expansion cards: To insert such expansion cards into the guide rails, they
must be equipped with an extender.
Note
Long expansion cards are only supported in a device with a standard enclosure.
Requirement
● The device is fully disconnected from the mains voltage; see section "Switching off the
device (Page 63)".
● The device is open; see section "Open the device (Page 76)".
Note
The accessory pack of the device includes three long card retainers for expansion cards with
low overall height. Use these instead of the card retainers installed in the device.
