Siemens SIMATIC Equipment Manual

I/O device digital inputs DI 16x24VDC M12-L 8xM12 (6ES7141-6BH00-0BB0)
Equipment Manual, 06/2021, A5E46570510-AB
17
Parameters/address space
4
4.1 Parameters
The table below shows the parameters for the I/O device digital inputs
DI 16x24VDC M12-L 8xM12.
Table 4- 1 Configurable parameters and their defaults (GSD file)
Parameters Value range Default Scope with configu-
ration software, e.g.
STEP 7 (TIA Portal)
Diagnostics: Undervoltage 1L+
• Disable
• Enable
Disable
Channel
Diagnostics: Short-circuit
• Disable
• Enable
Disable
Channel
Diagnostics: Wire break detection
and alarm
• Disable
• Enable
Disable
Channel
Input delay
• 0.05 ms
• 0.1 ms
• 0.4 ms
• 0.8 ms
• 1.6 ms
• 3.2 ms
• 12.8 ms
• 20 ms
3.2 ms
Channel
Hardware interrupt on rising
edge
• Disable
• Enable
Disable
Channel
Hardware interrupt on falling
edge
• Disable
• Enable
Disable
Channel
