Siemens SIMATIC Equipment Manual

I/O device digital inputs DI 16x24VDC M12-L 8xM12 (6ES7141-6BH00-0BB0)
30 Equipment Manual, 06/2021, A5E46570510-AB
Technical specifications
6
Technical specifications of the I/O device digital inputs DI 16x24VDC M12-L 8xM12
The following table shows the technical specifications as of the issue date. You can find a
data sheet including daily updated technical specifications on the Internet
(https://support.industry.siemens.com/cs/de/en/pv/6ES7141-6BH00-0BB0/td?dl=en).
Article number
6ES7141-6BH00-0BB0
General information
HW functional status
FS01
Firmware version
• FW update possible
Yes
Product function
• I&M data
Yes; I&M0 to I&M3
• Isochronous mode
Yes
• Prioritized startup
Yes
Engineering with
• STEP 7 TIA Portal configurable/integrated from
version
STEP 7 V17 or higher with HSP 0299
• PROFINET from GSD version/GSD revision
GSDML V2.3.x
Operating mode
• DI
Yes
• Counter
No
• MSI
Yes
Supply voltage
Load voltage 1L+
• Rated value (DC)
24 V
• permissible range, lower limit (DC)
20.4 V
• permissible range, upper limit (DC)
28.8 V
• Reverse polarity protection
Yes; Against destruction; encoder power supply
outputs applied with reversed polarity
Input current
Current consumption (rated value)
90 mA; without load
from load voltage 1L+ (unswitched voltage)
12 A; Maximum value
from load voltage 2L+, max.
12 A; Maximum value
