Siemens simovert masterdrives User Manual

10.99 Connecting-up
Siemens AG 6SE7087-6KP50
SIMOVERT MASTERDRIVES Operating Instructions 7-3
SIEMENS
A
S1
B
X101
CX103
P
PMU
External DC24 V supply,
RS485 (USS) X100
Bus terminating
resistor (USS) S1
Terminal strip X101
RS232/RS485 (USS) X103
Motor connection X2
PE3
−
+
Slot A
Slot B
Slot C
DC link bus module X3
Safe OFF (option) X533
Fig. 7-2 Connection overview of units 135 mm wide
