3.1 SENTRON PAC3200/4200
3.1.1 Hardware
Hardware components
You require the following hardware in order to be able to use all of the "Ctrl-Energy" functions:
● SENTRON PAC3200 (Firmware ≥ V2.2.0)
http://support.automation.siemens.com/WW/view/de/25240652/130000
● SENTRON PAC4200 (Firmware ≥ V1.4.0)
http://support.automation.siemens.com/WW/view/de/31675630/130000
● SENTRON PAC - accessories
http://www.automation.siemens.com/btlv-static/
Lowvoltage_LV10-1_complete_German_2011.pdf
– Power Monitoring Device (page 11/27 ff)
– Current transformer (Page 11/39)
● The expansion modules must be temporarily removed in order to upgrade the firmware
using powerconfig.
● Protection/fusing of the supply and measuring voltages according to Configuration Manual
● Expansion module PAC PROFINET; order number 7KM 9300-0AE01-0AA0
● Expansion module PAC PROFIBUS; order number 7KM 9300-0AB01-0AA0
● PC software powerconfig (≥ V2.2)
http://support.automation.siemens.com/WW/view/de/50246395
● Current transformer depending on
– the connection type at the SENTRON PAC
– Accuracy requirements
– Currents
DANGER
Open current transformer circuits result in electric shock and arcing
If not observed, will cause death, serious injury or considerable property damage.
Only measure the current using external current transformers. DO NOT protect the
circuits using a fuse. Do not open the secondary circuit of the current transformer under
load. Short circuit the secondary current terminals of the current transformer before
removing this device. The safety information for the current transformers used must
be carefully followed.
Selection example
Catalog, Siemens LV 1/Accessories and spare parts:
Ctrl-E Analysis
3.1 SENTRON PAC3200/4200
Ctrl-Energy
12 System Manual, 01/2015, 6FC5397-0EP40-5BA2
