For example, you activate the logical input address 132 by changing the machine data MD[...]
with entry 132 to -1.
● SENTRON PAC3200
I address
144 ... 147 Total active power
(value saved from SENTRON PAC)
148 ... 151 Active energy, imported, tariff 1 (instantaneous value)
152 ... 155 Active energy, exported, tariff 1 (instantaneous value)
For example, you activate the logical input address 144 by changing the machine data MD[...]
with entry 144 to -1.
The measured values are transferred in the float format.
References
Additional information about commissioning the PLC can be found in the following references:
SINUMERIK 828D Turning and Milling Commissioning Manual
3.3 Commissioning the PLC for Ctrl-E Analysis
3.3.1 Configuring the energy consumption display for SINUMERIK 840D sl
The energy consumption is displayed in the "SINUMERIK Ctrl-E Analysis" window.
See also
Signals for controlling energy-saving profiles (Page 44)
Signals for parameterization (Page 45)
The data block can be imported via the Toolbox and is loaded to the NCU via the user program.
Data block
DB1001
Name: SentronPac
Signal
direction
Meaning Identifier Format
DB1001.DBX0.0 PLC -> HMI Display manual value ManualVal BOOL
DB1001.DBX0.1 PLC -> HMI SENTRON PAC rep‐
resents the complete
machine
SentronPacMach BOOL
Ctrl-E Analysis
3.3 Commissioning the PLC for Ctrl-E Analysis
Ctrl-Energy
System Manual, 01/2015, 6FC5397-0EP40-5BA2 23
