Maximum times (HMI → PLC)
DB1000
DBW 16 Activation time T
1
DBW 18 Time for the prewarning limit T
2
Additional profile instances
DB1000
DBW 20 Energy-saving profile 2
DBW 40 Energy-saving profile 3
DBW 60 Energy-saving profile 4
DBW 80 Energy-saving profile 5
DBW 100 Energy-saving profile 6
DBW 120 Energy-saving profile 7
DBW 140 Energy-saving profile 8
4.1.6 Interface signals 828D
4.1.6.1 Signals for controlling energy-saving profiles
Dynamic data are cleared when the control powers up.
Control signals (user program)
DB9906
DBX0.0 Directly activate energy-saving profile
DBX0.1 Set time to prewarning limit
Control signals (HMI)
DB9906
DBX1.0 Directly activate energy-saving profile
Signals to check the energy-saving profile (user program)
DB9906
DBX2.0 Master computer prohibits energy-saving state
DBX2.1 PLC user program signal prohibits energy-saving state
Ctrl-E Profiles
4.1 Commissioning the PLC for Ctrl-E Profiles
Ctrl-Energy
46 System Manual, 01/2015, 6FC5397-0EP40-5BA2
