Status signals
DB9906
DBX4.0 Energy-saving profile is active
DBX4.1 Prewarning limit T1 reached
Actual values
DB9906
DBW6 Actual value T
1
DBW8 Actual value T
2
4.1.6.2 Signals for parameterization
Retentive parameterization data.
Effectiveness (HMI → PLC)
DB9906
DBX10.0 Energy-saving profile configured
DBX 10.1 Disable energy-saving profile
Masking (HMI → PLC)
DB9906
DBX11.0 Keyboard has been used
DBX11.1 Data transfer active
DBX11.2 Screen change active
DBX12.0 Machine control panel used
DBX13.0 NCK channel 1
DBX13.1 NCK channel 2
DBX15.0 Master computer prohibits*
DBX15.1 PLC user program signal prohibits*
*prohibits changing into the energy-saving mode.
Maximum times (HMI → PLC)
DB9906
DBW16 Activation time T
1
DBW18 Time for the prewarning limit T
2
Ctrl-E Profiles
4.1 Commissioning the PLC for Ctrl-E Profiles
Ctrl-Energy
System Manual, 01/2015, 6FC5397-0EP40-5BA2 47
