Siemens SIPART PS2 6DR5220 Series User Manual

Preparing for Operation
52
SIP ART PS2 Manual
A5E00074631-01
Figure 3-16 Series circuit of two positioners, e.g. split range (separate power supply)
3.4.1.3 Connection variant: Options in positioner in non--intrinsically safe and
explosion proof version
U
H
61
62
61
62
J
E
J
y
-module:
6DR4004-8J
+
+
Figure 3-17 J
y-
module 6DR4004-8J, non Ex
Split-range
Current output
