SIPART PS2 (6DR5...)
38 A5E03436620-06, 04/2015
7 Technical data
7.1 All device versions
7.1.1 Operating conditions
For use indoors and outdoors.
Ambient temperature In hazardous areas, observe the maximum permissible
ambient temperature corresponding to the temperature
• Permissible ambient temperature for operation
2)3)
-30 ... +80 °C (-22 ... +176°F)
• Height
2000 m above sea level. At altitudes greater than 2000 m
above sea level, use a suitable power supply.
IP66 to IEC/EN 60529 / NEMA 4X
Mounting position Any; in wet environment, pneumatic connections and
outlet opening not upward
• Harmonic oscillations (sine) according to EN 60068-2-
6/10.2008
3.5 mm (0.14"), 2 ... 27 Hz, 3 cycles/axle
98.1 m/s² (321.84 ft/s²), 27 ... 300 Hz, 3 cycles/axle
• Bumping (half-sine) according to EN 60068-2-27/02.2010
150 m/s² (492 ft/s²), 6 ms, 1000 shocks/axle
• Noise (digitally controlled) according to EN 60068-2-
64/04.2009
10 ... 200 Hz; 1 (m/s²)²/Hz (3.28 (ft/s²)²/Hz)
200 ... 500 Hz; 0.3 (m/s²)²/Hz (0.98 (ft/s²)²/Hz)
Recommended range of continuous operation of the entire
control valve
≤ 30 m/s² (98.4 ft/s²) without resonance peak
According to DIN EN 60721-3
1K5, but -40 ... +80°C (1K5, but -40 ... +176°F)
2K4, but -40 ... +80°C (2K4, but -40 ... +176°F)
Max. impact energy 1 Joule for enclosure with inspection window 6DR5..0 and 6DR5..1 or max. 2 Joule for 6DR5..3
At ≤ -10 °C (≤ 14 °F) the display refresh rate of the indicator is limited. When using position feedback module, only T4 is
permissible.
With Order suffix (Order code)
, the following applies to SIPART PS2 device version with and without HART: -40
... +80 °C (-40 ... +176°F)
