Siemens SIPART PS2 Compact Operating Instructions

SIPART PS2 (6DR5...)
42 A5E03436620-06, 04/2015
7.1.5 Certificates, approvals, explosion protection
Certificates and approvals
Classification according to pressure
equipment directive (PED 97/23/EC)
For fluid group 1 gases; fulfills requirements according to article 3, paragraph
3 (good engineering practice SEP)
CE conformity The applicable directives and applied standards with their revision levels can
be found in the EC declaration of conformity on the Internet.
See also
Certificates (http://www.siemens.com/processinstrumentation/certificates)
Explosion protection
Explosion protection
Ex markings
Explosion protection in accordance with
ATEX/IECEx
FM/CSA
Flameproof enclosure encapsulation "d",
"XP"
II 2 G Ex d IIC T6/T4 Gb
XP, Class I, Division 1, GP.ABCD
XP, Class I, Zone 1, AEx d, IIC, T6/T4
Intrinsic safety "i", "IS"
II 2 G Ex ia IIC T6/T4 Gb
II 3 G Ex ic IIC T6/T4 Gc
II 2 D Ex ia IIIC T110°C Db
IS / I, II, III / 1 / A-G
IS / 1 / AEx / Ex ib / IIC, Gb
IS / 21 / AEx / Ex ib / IIIC, Db, T110°C
Non-sparking "nA", "NI"
II 3 G Ex nA IIC T6/T4 Gc
NI / I / 2 / A-D
NI / 2 / AEx / Ex nA, Ex ic / IIC, Gc
Dust, protection by means of enclosure
"t", "DIP"
• For aluminum enclosure, narrow,
single-acting, without window
6DR5..
1
-.D...-..A.-Z ...
• For stainless steel enclosure
6DR5..
2
-.D...-..A.-Z ...
• For aluminum enclosure, with window
6DR5..3-.K...-..A.-Z ...
II 2 D Ex tb IIIC T100°C Db
DIP / II, III / 1 / E-G
DIP / 21 / AEx / Ex tb / IIIC, Db,
T100°C
Breakdown of the article numbers for assignment of the maximum permissible ambient temperature ranges
6DR5ayb-
0cdef-
g..h-
Z ...
a = 0, 2, 5, 6
c = E, G, D, F, K
g = 0, 2, 6, 7, 8
. = any character
y = 1, 2
d = G, N, M, P, R, S
h = 0, 1, 2, 3, 4, 9
b = 0, 1, 2, 3
e = 0, 1, 2, 3
f = 0, 1, 2, 3
Maximum permissible ambient temperature ranges with types of protection Ex ia, Ex ic and Ex nA
Explosion protection in accordance with
ATEX/IECEx
FM/CSA
With and without HART
• 6DR5
a
yb-0
c
def-g.Ah-Z ...
with the data (a = 0 or 2) and (c = D or
K)
T4: -30 ≤ T
a
≤ +80 °C (-22 ≤ T
a
≤ +176 °F)
T6: -30 ≤ T
a
≤ +50 °C (-22 ≤ T
a
≤ +122 °F)
•
6DR5ayb-0cdef-g.Ah-Z M40
with the data (a = 0 or 2) and (c = E)
T4: -40 ≤ T
a
≤ +80 °C (-40 ≤ T
a
≤ +176 °F)
T6: -40 ≤ T
a
≤ +50 °C (-40 ≤ T
a
≤ +122 °F)
PROFIBUS PA or
FOUNDATION Fieldbus
1)2)
• 6DR5
a
yb-0cdef-g.Ah-Z ...
with the data (a = 5 or 6)
T4: -20 ≤ T
a
≤ +75 °C (-4 ≤ T
a
≤ +167 °F)
T6: -20 ≤ T
a
≤ +50 °C (-4 ≤ T
a
≤ +122 °F)
