Siemens SIPART PS2 Compact Operating Instructions

SIPART PS2 (6DR5...)
50 A5E03436620-06, 04/2015
Without explosion
protection or suitable for
use in the SIPART PS2
Ex d
With Ex protection Ex "ia"
With Ex protection
Ex "ic", "nA", "t"
Galvanic isolation
The three outputs, the BI2 input and the basic device are galvanically isolated from
each other.
Test voltage
DC 840 V, 1 s
7.5.2 Position feedback module
Without explosion
protection or suitable for
use in the SIPART PS2
Ex d
With Ex protection Ex ia
(only in temperature class
T4)
With Ex protection
Ex "ic", "nA", "t"
Position feedback module
Direct current output for position
feedback
6DR4004-8J 6DR4004-6J 6DR4004-6J
1 current output, terminals 61 and 62
2-wire connection
Rated signal range
4 ... 20 mA, short-circuit proof
Dynamic range
3.6 ... 20.5 mA
Auxiliary voltage U
H
+12 ... +35 V
+12 ... +30 V
+12 ... +30 V
External load R
B
[kΩ]
≤ (U
H
[V] - 12 V)/I [mA]
Transmission error
≤ 0.3 %
Temperature influence
≤ 0.1%/10 K (≤ 0.1%/18 °F)
Resolution
≤ 0.1 %
Residual ripple
≤ 1 %
For connecting to circuits with the
following peak values
U
i
= DC 30 V
I
i
= 100 mA
P
i
= 1 W
"ic":
U
i
= DC 30 V
I
i
= 100 mA
"nA"/"t":
U
n
≤ DC 30 V
I
n
≤ 100 mA
P
n
≤ 1 W
Effective internal capacitance
-
C
i
= 11 nF
C
i
= 11 nF
Effective internal inductance
-
L
i
= negligibly small
L
i
= negligibly small
Galvanic isolation
Safe galvanic isolation from alarm option and basic device
Test voltage
DC 840 V, 1 s
